SiENBE37-704 Specifications
Specifications 43
Concealed Ceiling Unit (Large)
1-1 TECHNICAL SPECIFICATIONS FXMQ40MAVE FXMQ50MAVE FXMQ63MAVE FXMQ80MAVE
Nominal
Capacitry
Cooing kW 4.50 5.60 7.10 9.00
Heating kW 5.00 6.30 8.00 10.00
Power input
(Nominal)
Cooing kW 0.211 0.211 0.211 0.284
Heating kW 0.211 0.211 0.211 0.284
Casing Material Galvanised steel
Dimensions Unit Height mm 390 390 390 390
Width mm 720 720 720 720
Depth mm 690 690 690 690
Weight Unit kg 44 44 44 45
Heat
Exchanger
Dimensions
Nr of Rows 3 3 3 3
Fin Pitch mm 2.00 2.00 2.00 2.00
Face Area m² 0.181 0.181 0.181 0.181
Nr of Stages 16 16 16 16
Fan Type Sirocco fan
Quantity 1 1 1 1
Air Flow
Rate
Cooling High m³/min 14.00 14.00 14.00 19.50
Low m³/min 11.50 11.50 11.50 16.00
Fan External
static
pressure
High Pa 157 157 157 157
Standard Pa 118 118 118 108
Motor Quantity 1 1 1 1
Model D11/2D3AB1VE D11/2D3AB1VE D11/2D3AB1VE D11/2D3AA1VE
Output
(high)
W 100 100 100 160
Drive Direct drive
Refrigerant Name R-410A
Cooling Sound
Pressure
High dBA 39.0 39.0 39.0 42.0
Low dBA 35.0 35.0 35.0 38.0
Piping
connections
Liquid
(OD)
Type Flare connection
Diameter mm 6.4 6.4 9.5 9.5
Gas Type Flare connection
Diameter mm 12.7 12.7 15.9 15.9
Drain Diameter mm 32 32 32 32
Heat Insulation Glass fiber
Refrigerant control Electronic expansion valve
Temperature control Microprocessor thermostat for cooling and heating
Safety devices PC board fuse
Fan motor thermal protector
Standard
Accessories
Standard Accessories Installation and operation manual
Drain hose
Sealing Pads
Clamps
Screws
Insulation for fitting
Clamp metal
Notes Nominal cooling capacities are based on : indoor temperature : 27°CDB, 19°CWB, outdoor temperature : 35°CDB,
equivalent refrigerant piping : 7.5m (horizontal)
Nominal heating capacities are based on : indoor temperature : 20°CDB, outdoor temperature : 7°CDB, 6°CWB,
equivalent refrigerant piping : 7.5m (horizontal)
Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
The external static pressure is changeable : change the connectors inside the electrical box, this pressure means :
High static pressure-standard
Air filter is not standard accessory, but please mount it in the duct system of the suction side.
Select its colorimetric method (gravity method) 50% or more.
Sound pressure levels are measured at 220V
