Specifications SiENBE37-704
48 Specifications
Wall Mounted Unit
1-1 TECHNICAL SPECIFICATIONS FXAQ20MAVE FXAQ25MAVE FXAQ32MAVE FXAQ40MAVE FXAQ50MAVE FXAQ63MAVE
Nominal
Capacity
Cooling kW 2.20 2.80 3.60 4.50 5.60 7.10
Heating kW 2.50 3.20 4.00 5.00 6.30 8.00
Power input
(Nominal)
Cooling kW 0.016 0.022 0.027 0.020 0.027 0.050
Heating kW 0.024 0.027 0.032 0.020 0.032 0.060
Casing Colour white (3.0Y8.5/0.5)
Dimensions Unit Height mm 290 290 290 290 290 290
Width mm 795 795 795 1,050 1,050 1,050
Depth mm 230 230 230 230 230 230
Weight Unit kg 11 11 11 14 14 14
Heat
Exchanger
Dimensions
Nr of Rows 2 2 2 2 2 2
Fin Pitch mm 1.40 1.40 1.40 1.40 1.40 1.40
Face Area m² 0.161 0.161 0.161 0.213 0.213 0.213
Nr of Stages 14 14 14 14 14 14
Fan Type Cross flow fan
Quantity 1 1 1 1
Air Flow
Rate
Cooling High m³/min 7.50 8.00 9.00 12.00 15.00 19.00
Low m³/min 4.50 5.00 5.50 9.00 12.00 14.00
Fan Motor Quantity 1 1 1 1 1 1
Model QCL9661M QCL9661M QCL9661M QCL9686M QCL9686M QCL9686M
Output
(high)
W 40 40 40 43 43 43
Drive Direct drive
Refrigerant Name R-410A
Cooling Sound
Pressure
High dBA 35.0 36.0 37.0 39.0 42.0 46.0
Low dBA 29.0 29.0 29.0 34.0 36.0 39.0
Piping
connections
Liquid
(OD)
Type Flare connection
Diameter mm 6.4 6.4 6.4 6.4 6.35 9.5
Gas Type Flare connection
Diameter mm 12.7 12.7 12.7 12.7 12.7 15.9
Drain Diameter mm 18 18 18 18 18 18
Heat Insulation Foamed polystyrene/polyethylene
Air Filter Washable resin net
Refrigerant control Electronic expansion valve
Temperature control Microprocessor thermostat for cooling and heating
Safety devices PC board fuse
Standard
Accessories
Standard Accessories Installation and operation manual
Installation panel
Paper pattern for installation
Insulation tape
Clamps
Screws
Notes Nominal cooling capacities are based on : indoor temperature : 27°CDB, 19°CWB, outdoor temperature : 35°CDB,
equivalent refrigerant piping : 5m (horizontal)
Nominal heating capacities are based on : indoor temperature : 20°CDB, outdoor temperature : 7°CDB, 6°CWB,
equivalent refrigerant piping : 5m (horizontal)
Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
