Specifications SiENBE37-704
54 Specifications
4-way Blow Ceiling Suspended Unit
Notes:
H1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp.: 35°CDB / Equivalent piping length: 7.5m, level
difference: 0m.
H2 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp.: 35°CDB / Equivalent piping length: 7.5m, level
difference: 0m.
H3 Indoor temp. : 20°CDB / outdoor temp.: 7°CDB, 6°CWB / Equivalent piping length: 7.5m, level difference:
0m. (Heat pump only)
4 Capacities are net, including a deduction for cooling (an additional for heating) for indoor fan motor heat.
H5 Anechoic chamber conversion value, measured at a point 1.5m downward from the unit center. These
values are normally somewhat higher during actual operation as a result of ambient conditions.
Model
Indoor Unit
FXUQ71MAV1 FXUQ100MAV1 FXUQ125MAV1
Connection Unit
BEVQ71MAVE BEVQ100MAVE BEVQ125MAVE
H
1 Cooling Capacity (19.5°CWB)
kcal/h 7,100 10,000 12,500
Btu/h 28,300 39,600 49,500
kW 8.3 11.6 14.5
H
2 Cooling Capacity (19.0°CWB) kW 8.0 11.2 14.0
H
3 Heating Capacity
kcal/h 7,700 10,800 12,000
Btu/h 30,700 42,700 47,800
kW 9.0 12.5 14.0
Casing Color White (10Y9/0.5) White (10Y9/0.5) White (10Y9/0.5)
Dimensions: (H×W×D) mm 165×895×895 230×895×895 230×895×895
Coil (Cross
Fin Coil)
Rows×Stages×Fin Pitch mm 3×6×1.5 3×8×1.5 3×8×1.5
Face Area m² 0.265 0.353 0.353
Fan
Model QTS48A10M QTS50B15M QTS50B15M
Type Turbo Fan Turbo Fan Turbo Fan
Motor Output × Number
of Units
W 45×1 90×1 90×1
Air Flow Rate (H/L)
m³/min 19/14 29/21 32/23
cfm 671/494 1,024/741 1,130/812
Drive Direct Drive Direct Drive Direct Drive
Temperature Control
Microprocessor Thermostat for
Cooling and Heating
Microprocessor Thermostat for
Cooling and Heating
Microprocessor Thermostat for
Cooling and Heating
Sound Absorbing Thermal Insulation Material
Heat Resistant Foamed Polyethylene,
Regular Foamed Polyethylene
Heat Resistant Foamed Polyethylene,
Regular Foamed Polyethylene
Heat Resistant Foamed Polyethylene,
Regular Foamed Polyethylene
Piping
Connections
Liquid Pipes mm φ9.5 (Flare Connection) φ9.5 (Flare Connection) φ9.5 (Flare Connection)
Gas Pipes mm φ15.9 (Flare Connection) φ15.9 (Flare Connection) φ15.9 (Flare Connection)
Drain Pipe mm I.Dφ20×O.Dφ26 I.Dφ20×O.Dφ26 I.Dφ20×O.Dφ26
Machine Weight (Mass) kg 25 31 31
H
5 Sound Level (H/L) dBA 40/35 43/38 44/39
Safety Devices Thermal Protector for Fan Motor Thermal Protector for Fan Motor Thermal Protector for Fan Motor
Standard Accessories
Operation Manual, Installation
Manual, Drain Hose, Clamp Metal,
Insulation for Fitting, Sealing Pads,
Clamps, Screws, Washers, Holding
Plate.
Operation Manual, Installation
Manual, Drain Hose, Clamp Metal,
Insulation for Fitting, Sealing Pads,
Clamps, Screws, Washers, Holding
Plate.
Operation Manual, Installation
Manual, Drain Hose, Clamp Metal,
Insulation for Fitting, Sealing Pads,
Clamps, Screws, Washers, Holding
Plate.
Drawing No. C:4D045395A
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3412
cfm=m³/min×35.3
