SiENBE37-704 Specifications
Specifications 55
BEV Units
Model BEVQ71MAVE BEVQ100MAVE BEVQ125MAVE
Power Supply 1 Phase 50Hz 220~240V 1 Phase 50Hz 220~240V 1 Phase 50Hz 220~240V
Casing Galvanized Steel Plate Galvanized Steel Plate Galvanized Steel Plate
Dimensions: (H×W×D) mm 100×350×225 100×350×225 100×350×225
Sound Absorbing Thermal Insulation Material
Flame and Heat Resistant Foamed
Polyethylene
Flame and Heat Resistant Foamed
Polyethylene
Flame and Heat Resistant Foamed
Polyethylene
Piping
Connection
Indoor
Unit
Liquid Pipes 9.5mm (Flare Connection) 9.5mm (Flare Connection) 9.5mm (Flare Connection)
Gas Pipes 15.9mm (Flare Connection) 15.9mm (Flare Connection) 15.9mm (Flare Connection)
Outdoor
Unit
Liquid Pipes
9.5mm (Flare Connection) 9.5mm (Flare Connection) 9.5mm (Flare Connection)
Suction Gas Pipes
15.9mm (Flare Connection) 15.9mm (Flare Connection) 15.9mm (Flare Connection)
Machine Weight (Mass) kg 3.0 3.0 3.5
Standard Accessories
Installation manual, Gas piping
connections, Insulation for fitting,
Sealing material, Clamps
Installation manual, Gas piping
connections, Insulation for fitting,
Sealing material, Clamps
Installation manual, Gas piping
connections, Insulation for fitting,
Sealing material, Clamps
Drawing No. 4D045387A 4D045387A 4D045388A
