Specifications SiENBE37-704
56 Specifications
1.3 BS Units
Note: H1 When connecting with a 20 to 50 class indoor unit, connect to the attached pipe to the field pipe.
(Braze the connection between the attached and field pipe.)
H2 When connecting with an indoor unit of 150 or more and 160 or less, connect to the attached pipe to the field pipe.
(Braze the connection between the attached and field pipe.)
H3 When connecting with a 200 class, or more than 160 and less than 200 class indoor unit, connect to the attached pipe to the field pipe.
(Braze the connection between the attached and field pipe.)
Connection Range for BS Unit
Note: H Values inside brackets are based on connection of indoor units rated at maximum capacity, 200% from single outdoor units, 160% from
double outdoor units, 130% from triple outdoor units.
Model BSVQ100PV1 BSVQ160PV1 BSVQ250PV1
Power Supply 1 Phase 50Hz 200-240V 1 Phase 50Hz 200-240V 1 Phase 50Hz 200-240V
Total Capacity Index of Indoor Unit 20 to 100 More than 100 but 160 or less More than 160 but 250 or less
No. of Connectable Indoor Units Max. 5 Max. 8 Max. 8
Casing Galvanized steel plate Galvanized steel plate Galvanized steel plate
Dimensions: (H×W×D) mm 207×388×326 207×388×326 207×388×326
Sound Absorbing Thermal Insulation
Material
Foamed polyurethane, Flame resistant
needle felt
Foamed polyurethane, Flame resistant
needle felt
Foamed polyurethane, Flame resistant
needle felt
Piping
Connection
Indoor
Unit
Liquid Pipes 9.5mm C1220T (brazing connection) H1 9.5mm C1220T (brazing connection) 9.5mm C1220T (brazing connection)
Gas Pipes
15.9mm C1220T (brazing connection)
H
1 15.9mm C1220T (brazing connection)
H
2 22.2mm C1220T (brazing connection)
H
3
Outdoor
Unit
Liquid Pipes 9.5mm C1220T (brazing connection) 9.5mm C1220T (brazing connection) 9.5mm C1220T (brazing connection)
Suction Gas Pipes
15.9mm C1220T (brazing connection) 15.9mm C1220T (brazing connection)
H
2 22.2mm C1220T (brazing connection)
H
3
HP/LP Gas Pipes
12.7mm C1220T (brazing connection) 12.7mm C1220T (brazing connection)
H
2 19.1mm C1220T (brazing connection)
H
3
Weight kg 14 14 15
Standard Accessories
Installation manual, Attached pipe
Insulation pipe cover, Clamps
Installation manual, Attached pipe
Insulation pipe cover, Clamps
Installation manual, Attached pipe
Insulation pipe cover, Clamps
Drawing No. C: 4D057926 C: 4D057927 C: 4D057928
REYQ16P
Same number of
BS units
REYQ18P
REYQ8P
REYQ10P
REYQ12P
REYQ14P
REYQ20P
REYQ22P
REYQ24P
REYQ26P
REYQ28P
REYQ30P
Indoor unit total capacity
Outdoor unit
model name
Total capacity of connectable indoor
units
Number of connectable
indoor units
Components
REYQ36P
REYQ38P
REYQ32P
REYQ34P
REYQ40P
REYQ42P
REYQ44P
REYQ46P
REYQ48P
100 to 260 (400)
125 to 325 (500)
150 to 390 (600)
175 to 455 (700)
200 to 520 (800)
225 to 585 (720)
250 to 650 (800)
275 to 715 (880)
300 to 780 (960)
325 to 845 (1,040)
350 to 910 (1,120)
375 to 975 (1,200)
400 to 1,040 (1,280)
425 to 1,105 (1,105)
450 to 1,170 (1,170)
475 to 1,235 (1,235)
500 to 1,300 (1,300)
525 to 1,365 (1,365)
550 to 1,430 (1,430)
575 to 1,495 (1,495)
600 to 1,560 (1,560)
13 (20)
16 (25)
19 (30)
22 (35)
26 (40)
29 (36)
32 (40)
35 (44)
39 (48)
42 (52)
45 (56)
48 (60)
52 (64)
55 (55)
58 (58)
61 (61)
64 (64)
