TRACO POWER TXLN 025-103 [3/4] Txln 025 series 25 watt
![TRACO POWER TXLN 025-103 [3/4] Txln 025 series 25 watt](/views2/1707093/page3/bg3.png)
EMI Emissions
EN 61000-6-3 (Generic Residential)
- Conducted Emissions
EN 55032 class B (internal filter)
- Radiated Emissions
EN 55032 class B (internal filter)
- Harmonic Current Emissions
EN 61000-3-2, class A
- Voltage Fluctuations & Flicker
EN 61000-3-3
EMS Immunity
EN 55024 (IT Equipment)
- Electrostatic Discharge
Air:
EN 61000-4-2, ±8 kV, perf. criteria A
Contact:
EN 61000-4-2, ±4 kV, perf. criteria A
- RF Electromagnetic Field
EN 61000-4-3, 20 V/m, perf. criteria A
- EFT (Burst) / Surge
EN 61000-4-4, ±2 kV, perf. criteria A
L to L:
EN 61000-4-5, ±1 kV, perf. criteria A
L to PE:
EN 61000-4-5, ±2 kV, perf. criteria A
- Conducted RF Disturbances
EN 61000-4-6, 3 Vrms, perf. criteria A
- PF Magnetic Field
Continuous:
EN 61000-4-8, 3 A/m, perf. criteria A
- Voltage Dips & Interruptions
230 VAC / 50 Hz:
EN 61000-4-11
30%, 25 periods, perf. criteria A
>95%, 0.5 periods, perf. criteria A
>95%, 250 periods, perf. criteria C
EMC Specifications
Relative Humidity
90% max. (non condensing)
Temperature Ranges
- Operating Temperature
–20°C to +70°C
- Storage Temperature
–40°C to +85°C
Power Derating
- High Temperature
2.5 %/K above 50°C
Cooling System
Natural convection (20 LFM)
Altitude During Operation
2'000 m max.
Switching Frequency
65 kHz typ. (PWM)
Insulation System
Reinforced Insulation
Isolation Test Voltage
- Input to Output, 60 s
3'000 VAC
- Input to Case or PE, 60 s
1'500 VAC
- Output to Case or PE, 60 s
500 VAC
Isolation Resistance
- Input to Output, 500 VDC
100 MΩ min.
Leakage Current
(at 264 VAC)
- Earth Leakage Current
500 µA max.
Reliability
- Calculated MTBF
450'000 h
Housing Material
Aluminium
Connection Type
Screw Terminal
Weight
180 g
Status Indicator
Indicated by green LED
Environmental Compliance
- REACH Declaration
www.tracopower.com/info/reach-declaration.pdf
REACH SVHC list compliant
REACH Annex XVII compliant
- RoHS Declaration
www.tracopower.com/info/rohs-declaration.pdf
Exemptions: 6a, 6b, 6c, 7a, 7c-I, 7c-II
General Specifications
Supporting Documents
Overview Link (for additional Documents)
www.tracopower.com/overview/txln025
TXLN 025 Series, 25 Watt
All specifications valid at nominal voltage, full load and +25°C after warm-up time unless otherwise stated.
www.tracopower.com
February 3, 2021
Page 3 / 4
