Specifications Si39-501
42 Specifications
Ceiling Suspended Cassette Type
Notes:
1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp.: 35°CDB / Equivalent piping length: 7.5m, level
difference: 0m.
2 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp.: 35°CDB / Equivalent piping length: 7.5m, level
difference: 0m.
3 Capacities are net, including a deduction for cooling (an additional for heating) for indoor fan motor heat.
4 Anechoic chamber conversion value, measured at a point 1.5m downward from the unit center. These
values are normally somewhat higher during actual operation as a result of ambient conditions.
Model
Indoor Unit
FXUQ71MV1 FXUQ100MV1 FXUQ125MV1
Connection Unit
BEVQ71MVE BEVQ100MVE BEVQ125MVE
1 Cooling Capacity (19.5°CWB)
kcal/h 7,100 10,000 12,500
Btu/h 28,300 39,600 49,500
kW 8.3 11.6 14.5
2 Cooling Capacity (19.0°CWB) kW 8.0 11.2 14.0
Casing Color White (10Y9/0.5) White (10Y9/0.5) White (10Y9/0.5)
Dimensions: (H×W×D) mm 165×895×895 230×895×895 230×895×895
Coil (Cross
Fin Coil)
Rows×Stages×Fin Pitch mm 3×6×1.5 3×8×1.5 3×8×1.5
Face Area m² 0.265 0.353 0.353
Fan
Model QTS48A10M QTS50B15M QTS50B15M
Type Turbo Fan Turbo Fan Turbo Fan
Motor Output × Number
of Units
W 45×1 90×1 90×1
Air Flow Rate (H/L)
m³/min 19/14 29/21 32/23
cfm 671/494 1,024/741 1,130/812
Drive Direct Drive Direct Drive Direct Drive
Temperature Control
Microprocessor Thermostat for
Cooling
Microprocessor Thermostat for
Cooling
Microprocessor Thermostat for
Cooling
Sound Absorbing Thermal Insulation Material
Heat Resistant Foamed Polyethylene,
Regular Foamed Polyethylene
Heat Resistant Foamed Polyethylene,
Regular Foamed Polyethylene
Heat Resistant Foamed Polyethylene,
Regular Foamed Polyethylene
Piping
Connections
Liquid Pipes mm
φ
9.5 (Flare Connection)
φ
9.5 (Flare Connection)
φ
9.5 (Flare Connection)
Gas Pipes mm
φ
15.9 (Flare Connection)
φ
15.9 (Flare Connection)
φ
15.9 (Flare Connection)
Drain Pipe mm I.D
φ
20×O.D
φ
26 I.D
φ
20×O.D
φ
26 I.D
φ
20×O.D
φ
26
Machine Weight (Mass) kg 25 31 31
4 Sound Level (H/L) dBA 40/35 43/38 44/39
Safety Devices Thermal Protector for Fan Motor Thermal Protector for Fan Motor Thermal Protector for Fan Motor
Standard Accessories
Operation Manual, Installation
Manual, Drain Hose, Clamp Metal,
Insulation for Fitting, Sealing Pads,
Clamps, Screws, Washers, Holding
Plate.
Operation Manual, Installation
Manual, Drain Hose, Clamp Metal,
Insulation for Fitting, Sealing Pads,
Clamps, Screws, Washers, Holding
Plate.
Operation Manual, Installation
Manual, Drain Hose, Clamp Metal,
Insulation for Fitting, Sealing Pads,
Clamps, Screws, Washers, Holding
Plate.
Drawing No. C:4D045395
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3412
cfm=m³/min×35.3
