• Inverter heat pump • RXYQ5M7W1B, RXYQ8,10M8W1B
18
3
• Systems • Outdoor Units
110
3 Capacity tables
3-2 Heating capacity
3-2-9 22HP
TC: Total capacity; PI: Power Input
Combination (%) Capacity index
Outdoor
air temp.
Indoor air temperature: °CDB
16.0 18.0 20.0 21.0 22.0 24.0
TC PI TC PI TC PI TC PI TC PI TC PI
°CDB °CWBkWkWkWkWkWkWkWkWkWkWkWkW
130 715
-19.8 -20.0 37.3 8.47 37.2 9.53 37.0 10.6 36.9 11.1 36.9 11.7 36.7 12.7
-18.8 -19.0 38.6 9.15 38.5 10.2 38.3 11.2 38.3 11.7 38.2 12.2 38.0 13.2
-16.7 -17.0 41.3 10.4 41.1 11.3 40.9 12.3 40.9 12.8 40.8 13.2 40.6 14.2
-14.7 -15.0 43.9 11.4 43.7 12.3 43.6 13.2 43.5 13.7 43.4 14.1 43.2 15.0
-12.6 -13.0 46.5 12.4 46.3 13.2 46.2 14.1 46.1 14.5 46.0 14.9 45.9 15.7
-10.5 -11.0 49.1 13.2 49.0 14.0 48.8 14.8 48.7 15.2 48.6 15.6 48.5 16.4
-9.5-10.050.413.650.314.450.115.150.015.549.915.949.816.7
-8.5 -9.1 51.6 13.9 51.4 14.7 51.3 15.4 51.2 15.8 51.1 16.2 51.0 16.9
-7.0 -7.6 53.6 14.4 53.4 15.2 53.2 15.9 53.2 16.2 53.1 16.6 52.9 17.3
-5.0 -5.6 56.2 15.1 56.0 15.7 55.9 16.4 55.8 16.8 55.7 17.1 55.5 17.8
-3.0 -3.7 58.7 15.6 58.5 16.3 58.3 16.9 58.3 17.2 58.2 17.6 58.0 18.2
0.0 -0.762.616.462.417.062.317.662.217.962.118.261.918.8
3.0 2.2 66.4 17.0 66.2 17.6 66.1 18.2 66.0 18.5 65.9 18.7 65.7 19.3
5.0 4.1 68.9 17.4 68.7 18.0 68.5 18.5 68.5 18.8 68.4 19.1 68.2 19.6
7.0 6.0 71.3 17.8 71.2 18.3 71.0 18.8 70.9 19.1 70.9 19.4 70.7 19.9
9.0 7.9 73.8 18.1 73.7 18.6 73.5 19.1 73.4 19.4 73.4 19.6 73.2 20.2
11.0 9.8 76.318.476.218.976.019.475.919.775.819.975.720.4
13.0 11.8 78.9 18.7 78.8 19.2 78.6 19.7 78.5 19.9 78.5 20.2 78.2 20.6
15.0 13.7 81.4 19.0 81.3 19.4 81.1 19.9 81.0 20.1 80.9 20.4 78.2 19.8
120 660
-19.8 -20.0 37.1 9.90 37.0 10.9 36.8 11.9 36.8 12.3 36.7 12.8 36.5 13.8
-18.8 -19.0 38.4 10.5 38.3 11.5 38.1 12.4 38.1 12.9 38.0 13.4 37.9 14.3
-16.7 -17.0 41.1 11.7 40.9 12.5 40.8 13.4 40.7 13.9 40.6 14.3 40.5 15.2
-14.7 -15.0 43.7 12.6 43.5 13.5 43.4 14.3 43.3 14.7 43.2 15.1 43.1 15.9
-12.6 -13.0 46.3 13.5 46.1 14.3 46.0 15.1 45.9 15.4 45.8 15.8 45.7 16.6
-10.5 -11.0 48.9 14.3 48.8 15.0 48.6 15.7 48.5 16.1 48.5 16.5 48.3 17.2
-9.5-10.050.214.650.115.349.916.149.816.449.816.849.617.5
-8.5 -9.1 51.4 14.9 51.2 15.6 51.1 16.3 51.0 16.7 50.9 17.0 50.8 17.7
-7.0 -7.6 53.3 15.4 53.2 16.1 53.1 16.7 53.0 17.1 52.9 17.4 52.8 18.1
-5.0 -5.6 56.0 16.0 55.8 16.6 55.7 17.3 55.6 17.6 55.5 17.9 55.4 18.5
-3.0 -3.7 58.4 16.5 58.3 17.1 58.2 17.7 58.1 18.0 58.0 18.3 57.9 18.9
0.0 -0.762.417.262.217.862.118.362.018.661.918.961.819.5
3.0 2.2 66.2 17.8 66.0 18.3 65.9 18.9 65.8 19.1 65.7 19.4 65.6 19.9
5.0 4.1 68.6 18.1 68.5 18.7 68.4 19.2 68.3 19.4 68.2 19.7 68.1 20.2
7.0 6.0 71.1 18.5 71.0 19.0 70.8 19.5 70.8 19.7 70.7 20.0 70.5 20.5
9.0 7.9 73.6 18.8 73.5 19.3 73.3 19.7 73.2 20.0 73.2 20.2 72.2 20.3
11.0 9.8 76.119.176.019.575.820.075.720.275.720.572.219.5
13.0 11.8 78.7 19.4 78.6 19.8 78.4 20.3 78.3 20.5 77.5 20.4 72.2 18.7
15.0 13.7 81.2 19.6 81.1 20.0 80.9 20.5 80.1 20.4 77.5 19.6 72.2 18.0
110 605
-19.8 -20.0 36.9 11.3 36.8 12.2 36.6 13.1 36.6 13.6 36.5 14.0 36.4 14.9
-18.8 -19.0 38.2 11.9 38.1 12.8 38.0 13.6 37.9 14.1 37.8 14.5 37.7 15.4
-16.7 -17.0 40.8 12.9 40.7 13.8 40.6 14.6 40.5 15.0 40.4 15.4 40.3 16.2
-14.7 -15.0 43.5 13.8 43.3 14.6 43.2 15.4 43.1 15.7 43.1 16.1 42.9 16.9
-12.6 -13.0 46.1 14.6 45.9 15.4 45.8 16.1 45.7 16.4 45.7 16.8 45.5 17.5
-10.5 -11.0 48.7 15.4 48.6 16.0 48.4 16.7 48.4 17.0 48.3 17.4 48.1 18.0
-9.5-10.050.015.749.916.349.717.049.717.349.617.649.518.3
-8.5 -9.1 51.2 16.0 51.0 16.6 50.9 17.2 50.8 17.5 50.8 17.9 50.6 18.5
-7.0 -7.6 53.1 16.4 53.0 17.0 52.9 17.6 52.8 17.9 52.7 18.2 52.6 18.8
-5.0 -5.6 55.7 16.9 55.6 17.5 55.5 18.1 55.4 18.4 55.3 18.7 55.2 19.2
-3.0 -3.7 58.2 17.4 58.1 17.9 58.0 18.5 57.9 18.8 57.8 19.0 57.7 19.6
0.0 -0.762.218.062.018.561.919.161.819.361.819.661.620.1
3.0 2.2 65.9 18.6 65.8 19.1 65.7 19.6 65.6 19.8 65.5 20.0 65.4 20.5
5.0 4.1 68.4 18.9 68.3 19.4 68.2 19.8 68.1 20.1 68.0 20.3 66.1 20.0
7.0 6.0 70.9 19.2 70.8 19.7 70.6 20.1 70.6 20.3 70.5 20.6 66.1 19.1
9.0 7.9 73.4 19.5 73.3 19.9 73.1 20.4 73.1 20.6 71.0 19.9 66.1 18.3
11.0 9.8 75.919.875.820.275.620.673.519.971.019.166.117.6
13.0 11.8 78.5 20.0 78.4 20.4 75.9 19.9 73.5 19.1 71.0 18.4 66.1 16.9
15.0 13.7 81.0 20.2 80.8 20.6 75.9 19.1 73.5 18.4 71.0 17.7 66.1 16.3
100 550
-19.8 -20.0 36.7 12.8 36.6 13.6 36.5 14.4 36.4 14.8 36.3 15.2 36.2 16.0
-18.8 -19.0 38.0 13.3 37.9 14.1 37.8 14.9 37.7 15.3 37.6 15.6 37.5 16.4
-16.7 -17.0 40.6 14.2 40.5 15.0 40.4 15.7 40.3 16.1 40.3 16.4 40.1 17.2
-14.7 -15.0 43.2 15.1 43.1 15.7 43.0 16.4 42.9 16.8 42.9 17.1 42.8 17.8
-12.6 -13.0 45.9 15.8 45.7 16.4 45.6 17.1 45.6 17.4 45.5 17.7 45.4 18.4
-10.5 -11.0 48.5 16.4 48.3 17.0 48.2 17.6 48.2 17.9 48.1 18.2 48.0 18.9
-9.5-10.049.816.749.717.349.517.949.518.249.418.549.319.1
-8.5 -9.1 51.0 17.0 50.8 17.5 50.7 18.1 50.7 18.4 50.6 18.7 50.5 19.3
-7.0 -7.6 52.9 17.4 52.8 17.9 52.7 18.5 52.6 18.8 52.6 19.0 52.4 19.6
-5.0 -5.6 55.5 17.8 55.4 18.4 55.3 18.9 55.2 19.2 55.2 19.4 55.0 20.0
-3.0 -3.7 58.0 18.3 57.9 18.8 57.8 19.3 57.7 19.5 57.7 19.8 57.5 20.3
0.0 -0.761.918.961.819.361.719.861.620.061.620.360.120.1
3.0 2.2 65.7 19.4 65.6 19.8 65.5 20.2 65.4 20.5 64.6 20.3 60.1 18.6
5.0 4.1 68.2 19.7 68.1 20.1 68.0 20.5 66.8 20.2 64.6 19.4 60.1 17.8
7.0 6.0 70.7 19.9 70.6 20.3
69.0 20.1 66.8 19.3 64.6 18.6 60.1 17.1
9.0 7.9 73.2 20.2 73.1 20.6 69.0 19.3 66.8 18.5 64.6 17.8 60.1 16.4
11.0 9.8 75.720.473.419.969.018.566.817.864.617.160.115.8
13.0 11.8 77.9 20.5 73.4 19.1 69.0 17.8 66.8 17.1 64.6 16.5 60.1 15.2
15.0 13.7 77.9 19.7 73.4 18.4 69.0 17.1 66.8 16.5 64.6 15.9 60.1 14.6
