Model Names of Indoor/Outdoor Units SiE39-404
2 General Information
1. Model Names of Indoor/Outdoor Units
Indoor Units
Indoor Units (Connection Unit Series)
Note: BEV unit is required for each indoor unit.
Outdoor Units
Type Model Name Power Supply
Ceiling Mounted
Cassette Type
(Double Flow)
FXCQ 20M 25M 32M 40M 50M 63M 80M — 125M — —
VE
Ceiling Mounted
Cassette Type
(Multi Flow) 600×600
FXZQ 20M 25M 32M 40M 50M — — — — — —
Ceiling Mounted
Cassette Type
(Multi Flow)
FXFQ — 25M 32M 40M 50M 63M 80M 100M 125M — —
Ceiling Mounted
Cassette Corner Type
FXKQ — 25M 32M 40M — 63M — — — — —
Slim Ceiling Mounted
Duct Type
FXDQ 20N 25N 32N 40N 50N 63N — — — — —
Ceiling Mounted
Built-In Type
FXSQ 20M 25M 32M 40M 50M 63M 80M 100M 125M — —
Ceiling Mounted
Duct Type
FXMQ — — — 40M 50M 63M 80M 100M 125M 200M 250M
Ceiling Suspended
Type
FXHQ — — 32M — — 63M — 100M — — —
Wall Mounted Type
FXAQ 20M 25M 32M 40M 50M 63M — — — — —
Floor Standing Type
FXLQ 20M 25M 32M 40M 50M 63M — — — — —
Concealed Floor
Standing Type
FXNQ 20M 25M 32M 40M 50M 63M — — — — —
Outdoor Air Processing
Unit
FXMQ-
MF
————————
125MF 200MF 250MF
V1
Type Model Name Power Supply
Ceiling Suspended
Cassette Type
FXUQ — — — — — — 71M 100M 125M — —
V1
Wall Mounted Type
FXAQ-MH
20MH 25MH 32MH 40MH 50MH
——————
Floor Standing Type
FXLQ-MH
20MH 25MH 32MH 40MH 50MH
——————
Connection Unit BEVQ-M 50M 50M 50M 50M 50M — 71M 100M 125M — — VE
Series Model Name Power Supply
Heat Pump RXYQ 5M 8M 10M 12M 14M 16M 18M 20M 22M 24M 26M Y1B
Series Model Name Power Supply
Heat Pump RXYQ 28M 30M 32M 34M 36M 38M 40M 42M 44M 46M 48M Y1B
VE: 1φ, 220~240V, 50Hz, 1φ, 220V, 60Hz
V1: 1φ, 220~240V, 50Hz
Y1B: 3φ, 380~415V, 50Hz
