Biostar Hi-Fi B150 PIO D4 Версия 6.x [4/33] 3 specifications
![Biostar Hi-Fi B150 PIO D4 Версия 6.x [4/33] 3 specifications](/views2/1707941/page4/bg4.png)
4 | Chapter 1: Introducon
1�3 Specicaons
Specicaons
CPU Support
Socket 1151 for Intel® Core i7 / i5 / i3 / Penum / Celeron processor
Maximum CPU TDP (Thermal Design Power): 95Wa
* Please refer to www.biostar.com.tw for CPU support list.
Chipset INTEL® B150
Memory
Supports Dual Channel DDR4 2133/1866
2x DDR4 DIMM Memory Slot, Max. Supports up to 32 GB Memory
Each DIMM supports non-ECC 4/8/16GB DDR4 module
* Please refer to www.biostar.com.tw for Memory support list.
Storage
4x SATA III Connector
supports AHCI
LAN
RTL8111H
1x 10/ 100/ 1000 Mb/s auto negoaon, Half / Full duplex capability
Audio Codec
ALC887
7.1 Channels, High Denion Audio, Biostar Hi-Fi (Rear)
USB
6x USB 3.0 port (4 on rear I/Os and 2 via internal header)
6x USB 2.0 port (2 on rear I/Os and 4 via internal header)
Expansion Slots
1x PCIe 2.0 x16 Slot (x16, 90 degree)
1x PCIe 3.0 x16 Slot (x4)
Rear I/Os
1x PS/2 Mouse
1x PS/2 Keyboard
1x DVI-D Port
1x VGA Port
1x LAN port
2x USB 2.0 Port
4x USB 3.0 Port
3x Audio Jack
Internal I/Os
4x SATA III Connector
2x USB 2.0 Header
1x USB 3.0 Header
1x 4-Pin Power Connector
1x 24-Pin Power Connector
1x CPU Fan Connector
1x System Fan Connector
1x Front Panel Header
1x Front Audio Header
1x Clear CMOS Header
1x HDMI Header
Form Factor uATX Form Factor, 203mm x 210mm
OS Support
Windows 7/ 8.1(64bit)/ 10(64bit)
Biostar reserves the right to add or remove support for any OS with or without noce.
