6 | Chapter 1: Introducon
1.5 Motherboard Layout
DDR4_A1
DDR3_A1
DDR4_B1
DDR3_B1
SATA_EXPRESS_1
SATA3_1U/1L SATA3_2U/2L
SATA3_3
SATA3_4
DVI-D
VGA
PEX1_1
PCI1
PEX16_1
PEX16_2
PCI2
PCI3
Z170
B150
USB3_0
COM
SYS_FAN1
CPU_FAN1
VGA_DVI1
Note
»
representsthe1stpin.
