www.tracopower.com Page 1 of 4

AC/DC Power Supplies

TOP 200 Series, 200 Watt

Features

◆ Highest power density in 5.0” x 3.0” footprint

◆

Supplies 200 W (convection cooling!)

◆ Highest efﬁciency up to 95%

◆ Operating temperature range –25°C to +70°C

◆ Universal input 85 – 264 VAC

◆ Compliance with EN 61000-3-2

◆ Power Back immunity

◆ Low leakage current

◆ Protection class l and class ll

◆ 3-year product warranty

The new TOP-200 Series AC/DC Power Supplies feature the highest power rating

in the industry standard 3.0” x 5.0” (76.2 x 127 mm) footprint. They can supply up

to 200 W output power with convection cooling over an industrial operating tem-

perature range of –25°C to +70°C. This performance could be realized by a state

of the art design providing an extremely high efﬁciency of >90 % which eliminates

the need for a dedicated power supply cooling fan.

Compliance with global safety and EMC standards qualify these power supplies for

worldwide markets. Approved for Class l and Class ll applications, these switchers

are suitable for industrial and IT systems but also for consumer products. High reli-

ability is provided by use of industrial quality grade components and an excellent

thermal management. This product offers an interesting power supply solution for

many space and cost critical applications in commercial and industrial electronic

equipment.

Order Code Output Power

max.

Output Voltage

(ﬁxed)

Output Current

max.

TOP 200-112 12 VDC

16 A

TOP 200-115

200 W

15 VDC

13 A

TOP 200-124 24 VDC

8.3 A

TOP 200-148 48 VDC

4.2 A

Models

C B

Scheme

UL 60950-1
