www.tracopower.com Page 3 of 4
All specifications valid at nominal input voltage, full load and +25°C after warm-up time unless otherwise stated.
AC/DC Power Supplies
TOP-200 Series 200 Watt
General Specifications
Humidity (non condensing) 0 – 95 % rel. H max.
Efficiency – Vin = 115 VAC 12 & 15 VDC models: 88 – 91 %
24 & 48 VDC models: 90 – 93 %
– Vin = 230 VAC 12 & 15 VDC models: 90 – 93 %
24 & 48 VDC models: 92 – 95 %
Switching frequency 100 kHz typ. (pulse width modulation)
Hold-up time 10 ms typ.
Start-up time – Vin = 115 VAC <3.0s
– Vin = 230 VAC <2.0s
Remote On/Off – On: open contacts on J3
– Off: see J3 remote On/Off function on last page
Isolation voltage – Input / Output 3000 VAC
– Input / Field Ground 1500 VAC
– Output / Field Ground 500 VAC
Isolation resistance (at 500 VDC) 100 Mohm min.
Earth leakage current 500 µA max.
Reliability, calculated MTBF at +25°C acc. to IEC 61709 www.tracopower.com/overview/top200
Safety class (for built in use only) class I, class II prepared with second fuse
Electromagnetic compatibility – Conducted input RI suppression EN 55022, class B (conductive plane to be
(EMC), emissions connected to field ground)
– Harmonic current emissions IEC/EN 61000-3-2, class A
Electromagnets compatibility – RF field immunity IEC/EN 61000-4-3, 20V/m criteria A
(EMC), immunity – Electrical fast transients/burst immunity IEC/EN 61000-4-4, ±2kV criteria B
– Surge IEC/EN 61000-4-5, ±1kV/±2kV criteria B
– Conducted RF IEC/EN 61000-4-6, 10V criteria A
– Magnetic field IEC/EN 61000-4-8, 100A/m criteria A
– Voltage dip IEC/EN 61000-4-11
– Voltage Sag immunity Semi F47-0706
Safety approvals and UL 60950-1, 2nd Ed + AM1
Certification CSA 60950-1-07-2nd Ed
IEC 60950-1:2005 (2nd Edition)
EN 60950-1:2006 + Am 1:2010 + Am
Certification documents: www.
tracopower.com/overview/top200
11:2009 + Am 12:2011
Environment – Vibration acc. IEC 60068-2-6; 3 axis, sine sweep, 10 – 55Hz, 0.075 mm
– Shock acc. IEC 60068-2-27 3 axis, 15g half sine, 11ms
Environmental compliance – Reach www.tracopower.com/info/reach-declaration.pdf
– RoHS RoHS directive 2011/65/EU
Connection pin connector (Molex)
Weight 315 g ( 8.93 oz)
