Hi-Fi Z87S 3D/Hi-Fi H87S 3D/Hi-Fi B85S 3D
59
Спецификации
Внутр. Плата
ввода-вывода
Hi-Fi Z87S 3D & Hi-Fi H87S 3D
Соединитель 6x SATA 6 Гб/с
2 контакта USB 2.0 (каждый контакт
поддерживает 2 порта USB 2.0)
1 контакт USB 3.0 (каждый контакт
поддерживает 2 порта USB 3.0)
1 8-выводный разъем питания
1 24-выводный разъем питания
1 разъем вентилятора ЦП
4 разъема вентилятора системы
1 контакт передней панели
1 контакт передней аудиопанели
1 контакт микросхемы Clear CMOS
1 инфракрасный пользовательский
контакт
1 контакт последовательного порта
1 соединитель S/PDIF-Out
Hi-Fi B85S 3D
Соединитель 4x SATA 6 Гб/с
Соединитель 2x SATA 3 Гб/с
2 контакта USB 2.0 (каждый контакт
поддерживает 2 порта USB 2.0)
1 контакт USB 3.0 (каждый контакт
поддерживает 2 порта USB 3.0)
1 8-выводный разъем питания
1 24-выводный разъем питания
1 разъем вентилятора ЦП
4 разъема вентилятора системы
1 контакт передней панели
1 контакт передней аудиопанели
1 контакт микросхемы Clear CMOS
1 инфракрасный пользовательский
контакт
1 контакт последовательного порта
1 соединитель S/PDIF-Out
Конструктив Форм-фактор ATX, 305 мм x 220 мм
Поддержка ОС
Windows 7/ 8
Biostar оставляет за собой право добавлять или удалять поддержку любой ОС, с
уведомлением или без.
