EMI Emissions
EN 61000-6-4 (Generic Industrial)
- Conducted Emissions
EN 55011 class B (internal filter)
EN 55032 class B (internal filter)
FCC Part 15, class B
- Radiated Emissions
EN 55011 class A (internal filter)
EN 55032 class A (internal filter)
FCC Part 15, class A
- Harmonic Current Emissions
EN 61000-3-2, class A
EN 61000-3-2, class D
- Voltage Fluctuations & Flicker
EN 61000-3-3
EMS Immunity
EN 55024 (IT Equipment)
- Electrostatic Discharge
Air:
EN 61000-4-2, ±8 kV, perf. criteria A
Contact:
EN 61000-4-2, ±6 kV, perf. criteria A
- RF Electromagnetic Field
EN 61000-4-3, 20 V/m, perf. criteria A
- EFT (Burst)
EN 61000-4-4, ±2 kV, perf. criteria A
- Surge
L to L:
EN 61000-4-5, ±1 kV, perf. criteria A
L to PE:
EN 61000-4-5, ±2 kV, perf. criteria A
- Conducted RF Disturbances
EN 61000-4-6, 20 Vrms, perf. criteria A
- PF Magnetic Field
Continuous:
EN 61000-4-8, 10 A/m, perf. criteria A
- Voltage Dips & Interruptions
230 VAC / 50 Hz:
EN 61000-4-11
30%, 25 periods, perf. criteria A
>95%, 0.5 periods, perf. criteria A
>95%, 250 periods, perf. criteria B
115 VAC / 60 Hz:
EN 61000-4-11
30%, 25 periods, perf. criteria A
>95%, 0.5 periods, perf. criteria A
>95%, 250 periods, perf. criteria B
EMC Specifications
Relative Humidity
95% max. (non condensing)
Temperature Ranges
- Operating Temperature
–40°C to +80°C
- Storage Temperature
–40°C to +85°C
-40°C start-up: 80% load max. at Vin >100 VAC
-40°C start-up: 100% load max. at Vin >200 VAC
Power Derating
- High Temperature
See application note:
www.tracopower.com/overview/tpi100a
- Low Input Voltage
1.33 %/V below 100 VAC
Cooling System
Natural convection (20 LFM)
Altitude During Operation
5'000 m max.
Switching Frequency
45 - 75 kHz (PWM QR)
Insulation System
Reinforced Insulation
Working Voltage (rated)
344 VAC
Isolation Test Voltage
- Input to Output, 60 s
3'000 VAC
- Input to Case or PE, 60 s
1'500 VAC
- Output to Case or PE, 60 s
1'500 VAC
Isolation Resistance
- Input to Output, 500 VDC
100 MOhm min.
Leakage Current
(at 264 VAC)
- Touch Current
300 µA max.
Reliability
- Calculated MTBF
790'000 h (MIL-HDBK-217F, ground benign)
Environment
- Vibration
IEC 60068-2-6
3 axis, sine sweep, 10 - 55 Hz, 1 g, 1 oct/min
- Mechanical Shock
IEC 60068-2-27
3 axis, 10 g half sine, 11 ms shock
20 g (3 directions each 3 times)
Connection Type
JST
Weight
156 g
General Specifications
TPI 100A Series, 100 Watt
All specifications valid at nominal voltage, full load and +25°C after warm-up time unless otherwise stated.
www.tracopower.com
September 10, 2019
Page 3 / 4
