Hi-Fi B85S1 & Hi-Fi H81S1
49
Especificações
Conectores na
placa
Hi-Fi B85S1
Conector 4x SATA 6.0Gb/s
Dispositivo 2x USB 2.0 (cada
Dispositivo suporta 2 portas USB 2.0)
Dispositivo 1x USB 3.0 (cada
Dispositivo suporta 2 portas USB 3.0)
Conector de 4 pinos x1
Conector de 24 pinos x1
Conector de Ventoinha processador x1
Conector de Ventoinha Sistema x1
Dispositivo Painel Frontal x1
Dispositivo de Audio Frontal x1
Dispositivo CMOS Direct x1
Dispositivo Porta Série x1
Conector Externo S/PDIF x1
Dispositivo Porta Impressora x1
Hi-Fi H81S1
Conector 2x SATA 6.0Gb/s
Conector 2x SATA 3.0Gb/s
Dispositivo 2x USB 2.0 (cada Dispositivo
suporta 2 portas USB 2.0)
Conector de 4 pinos x1
Conector de 24 pinos x1
Conector de Ventoinha processador x1
Conector de Ventoinha Sistema x1
Dispositivo Painel Frontal x1
Dispositivo de Audio Frontal x1
Dispositivo CMOS Direct x1
Dispositivo Porta Série x1
Conector Externo S/PDIF x1
Dispositivo Porta Impressora x1
Fator de Fôrma Fator de Fôrma microATX, 226 mm x 174 mm
Suporte OS
Windows 7/ 8/ 8.1
Biostar reserva seu direito de adicionar ou retirar o suporte para qualquer OS com ou sem
notificação.
