TRACO POWER TPI150-148A-J Datasheet онлайн
AC/DC Industrial Power Supply
TPI 150A Series, 150 Watt
•
Highest power density 150 W open
frame power supply in 2” x 4” package
•
I/O reinforced isolation 3000 VDC
•
Ready to meet ErP directive, < 0.3 W no
load power consumption
•
Highest efficiency 91 - 92% across 10%
- 100% load range
•
Active power factor correction > 95
•
Protection class II prepared
•
Operating up to 5000 m altitude
•
Adjustable output voltage
•
3-year product warranty
IEC 62368-1
UL 62368-1
The TPI 150A Series of 150 Watt AC/DC power supplies features a 3000 VDC
I/O reinforced isolation. Excellent efficiency of up to 92% allows a high power
density for the standard 2.0” x 4.0” packaging format. The full load operating
temperature range is –40°C to +50°C while it goes up to +80°C with load der-
ating. The power supplies are designed to meet the ErP directive (< 0.3 W no
load power consumption). They come with an active power factor correction
and the EMC characteristic is dedicated for applications in industrial and do-
mestic fields. High reliability is provided by use of industrial quality grade com-
ponents and an excellent thermal management. It makes the products an ideal
solution for any demanding industrial devices and space critical applications.
Models
Order Code
Output Power
max.
Output Voltage
nom. (adjustable)
Output Current max.
(Forced air cooling)
Output Current max.
(Natural convection)
Efficiency
typ.
TPI 150-112A-J
150 W
12 VDC (10.8 - 13.2 VDC)
12'500 mA
8'340 mA
91 %
TPI 150-115A-J
15 VDC (13.5 - 16.5 VDC)
10'000 mA
7'340 mA
92 %
TPI 150-124A-J
24 VDC (21.6 - 26.4 VDC)
6'250 mA
4'590 mA
92 %
TPI 150-128A-J
28 VDC (25.2 - 30.8 VDC)
5'360 mA
3'930 mA
92 %
TPI 150-136A-J
36 VDC (32.4 - 39.6 VDC)
4'170 mA
3'060 mA
92 %
TPI 150-148A-J
48 VDC (43.2 - 52.8 VDC)
3'130 mA
2'090 mA
92 %
www.tracopower.com
December 18, 2020
Page 1 / 4
