Hi-Fi A85W 3D
53
Спецификации
Внутр. Плата
ввода-вывода
Соединитель 8x SATA 6 Гб/с
2 контакта USB 2.0 (каждый контакт поддерживает 2 порта USB 2.0)
1 контакт USB 3.0 (каждый контакт поддерживает 2 порта USB 3.0)
1 4-выводный разъем питания
1 24-выводный разъем питания
1 разъем вентилятора ЦП
2 разъема вентилятора системы
1 контакт передней панели
1 контакт передней аудиопанели
1 контакт микросхемы Clear CMOS
1 инфракрасный пользовательский контакт
1 контакт последовательного порта
1 соединитель S/PDIF-Out
Конструктив Форм-фактор ATX, 305мм x 235 мм
Поддержка ОС
Windows XP / Vista / 7/ 8
Biostar оставляет за собой право добавлять или удалять поддержку любой ОС, с
уведомлением или без.
