Package Content

Thank you for purchased the PLANET FGSW-4840S, 48+4G

Ethernet Web Smart Switch.

Open the box of the Switch and carefully unpack it. The box

should contain the following items:

● WebSmartGigabitEthernetSwitchx1

● User’smanualCDx1

● Quickinstallationguidex1

● PowerCordx1

● Rubberfeetx4

● Tworack-mountingbracketswithattachmentscrewsx1

If any item is found missing or damaged, please contact your

local reseller for replacement.

Requirements

• Workstations of subscribers running Windows 98/2000/XP/

ME, NT4.0,MACOS9or later,Linux,UNIX orotherplatform

compatiblewithTCP/IPprotocols.

• WorkstationinstalledwithEthernetNIC(NetworkCard).

• Ethernet Port connect

 □ Network cables - Use standardnetwork (UTP) cables with

RJ45connectors.

 □ Above PC installed with Web Browser and JAVA runtime

environmentPlug-in.

Note

It is recommended to use Internet Explore

6.0orabovetoaccesstheSwitch.

Start Web Management

The following shows how to startup the Web Management of

the Switch, please note the Switch is congured through an

Ethernet connection, make sure the manager PC must be set

on the same IP subnet address.

For example, the default IP address of the Switch is

192.168.0.100, then the manager PC should be set at

192.168.0.x(wherexis anumberbetween 1 and 254,except

100),andthedefaultsubnetmaskis255.255.255.0.

1.Use Internet Explorer 6.0 or above Web browser, enter IP

addresshttp://192.168.0.100toaccesstheWebinterface.

2. When the Login page is shown, the system will ask you to

enter the username and password.

DefaultUsername:admin

DefaultPassword:admin

ThescreenappearsasFigure3-1.

Figure 3-1 Web Login Page screen

3. After entering the username and password, the main screen

appears as Figure 3-2.

Figure 3-2 Web Main Screen of Switch

Now, you can use the Web management interface to continue

the switch management. Please refer to the user manual for

more.

Customer Support

Thank you for purchase PLANET products. You can browse our

online FAQresource at thePLANETWeb site rst tocheck ifit

could solve you issue. If you need more support information,

please contact PLANET switch support team.

PLANETonlineFAQ:

http://www.planet.com.tw/support/faq.php

Switch support team mail address:

support_switch@planet.com.tw
