Planet FNSW-4800 [12/18] Caution

Figure 2-3 Attaching the brackets to the Switch

You must use the screws supplied with the mounting

brackets. Damage caused to the parts by using incorrect

screws would invalidate your warranty.

Step 3: Secure the brackets tightly.

Step 4: Follow the same steps to attach the second bracket to the

opposite side.

Step 5: After the brackets are attached to the Switch, use suitable

screws to securely attach the brackets to the rack, as shown

in Figure 2-4.

Figure 2-4 Mounting the Switch in a Rack

Step 6: Proceed with the steps 4 and steps 5 of section 2.3.1 Desktop

Installation to connect the network cabling and supply power

to your Switch.
