5
1. INTRODUCTION
1.1 Package Contents
Check the contents of your package for following parts:
● Desktop Fast Ethernet Switch x 1
● User’s manual x 1
● Power adapter x 1
If any of these are missing or damaged, please contact your dealer
immediately, if possible, retain the carton including the original packing
material, and use them against to repack the product in case there is a
need to return it to us for repair.
1.2 How to Use This Manual
This Desktop Fast Ethernet Switch User Manual is structured as follows:
Chapter 2 Installation
The chapter explains the feature, functionality and the physical
installation of the Switch.
Chapter 3 Switch operation
The chapter explains the Switch transmit operation.
Chapter 4 Troubleshooting
The chapter explains the troubleshooting of the Switch.
Appendix A
This chapter contains cable information of the Switch.
In the following section, the term “Desktop Fast Ethernet Switch”
means the two Switch devices, ie. SW-504 and SW-804; term of
“switch” can be any third switches.
