1.4 Rear Panel Connectors

H310MHG

H310MHG2

Note

 VGA/DVI-D/HDMIportsonlyworkwithanIntel®integratedGraphicsProcessor.



Maximumresoluon

VGA:1920x1200@60Hz

DVI-D:1920x1200@60Hz

HDMI:4096x2160@24Hz,compliantwithHDMI1.4



WhenusingthefrontHDaudiojackandplugintheheadset/microphone,therearsoundwillbe

automacallyDisabled.



Themainboardsupportstwoonboarddisplayoutputsatsamemeandthedisplayoutput

conguraoncanbeselectedinIntelgraphicsdriverulity.



Tocongure7.1-channelaudio,youhavetouseachassiswithHDfrontpanelaudiomoduleand

enablethemul-channelaudiofeaturethroughO.S.AudioUlity.

The 2/ 4/ 5.1/ 7.1-channel conguraon

Audio Port 2-channel 4-channel 5.1 channel 7.1 channel

Blue (Rear Panel) Line In Line In Line In Side Speaker Out

Green (Rear Panel) Line Out Front Speaker Out Front Speaker Out Front Speaker Out

Pink (Rear Panel) Mic In Mic In Center/Subwoofer Out Center/Subwoofer Out

Green (Front Panel) Headphone Rear Speaker Out Rear Speaker Out Rear Speaker Out
