http://www.tracopower.com Page 1 of 3

Industrial Power Supplies

TBL Series, 15 to 150 Watt

Features

◆ Low proﬁle case, module depth only 55mm

◆ Fits into ﬂat control panels used in

building automation

◆ Safety class ll product

◆ UL 1310 class II, NEC class 2 compliance

(models up to 90 W)

◆ UL 508 listed

◆ Power ranges from 12 to 150 W

◆ Universal input range 85 to 264 VAC

(auto range for 150 Watt models)

◆ Operating temperature range:

–25°C to +70°C max.

◆ Adjustable output voltage

◆ Short circuit and overload protection

◆ DC–OK indicator

◆ Easy snap-on mounting on DIN-rail

or with wall mounting bracket (included)

◆ 3-year product warranty

The TBL series is a new range of small DIN-rail mount power supplies which have

been designed particularly with building- and factory automation applications in

mind. The ultra-compact low proﬁle cases ﬁt in the standardized wall mounted con-

trol panels used in the building automation industry. The power supplies can be

operated at full load across an ambient temperature range of –25°C to +60°C with-

out need of additional cooling. Universal input voltage range and full compliance

with all important safety and EMC standards qualiﬁes the TBL series power sup-

plies for worldwide markets. For commercial and residential applications requesting

safety class ll the models up to 90 Watt are approved to UL 1310.

Order Code Output Power

(max.)

Output Voltage*

(nom.)

Output Current

(max.)

Efﬁciency

(typ.)

TBL 015-105 12 W 5.0 VDC 2.4 A 73 %

TBL 015-112 15 W 12 VDC 1.25 A 79 %

TBL 015-124 15 W 24 VDC 0.63 A 81 %

TBL 030-112 12 VDC 2.5 A 81 %

TBL 030-124

30 W

24 VDC 1.25 A 83 %

TBL 060-112 54 W 12 VDC 4.5 A 83 %

TBL 060-124 60 W 24 VDC 2.5 A 85 %

TBL 090-112 72 W 12 VDC 6.0 A 84 %

TBL 090-124 90 W 24 VDC 3.75 A 86 %

TBL 150-112 120 W 12 VDC 10 A 84 %

TBL 150-124 150 W 24 VDC 6.25 A 87 %

Models

* adjustable

UL508

Scheme

UL60950-1
