Biostar H81MGC-LSP Версия 7.x [12/37] Dual channel memory installation

Motherboard Manual

Memory Capacity

DIMM Socket

Location

DDR3 Module

Total Memory Size

DDR3_A1 512MB/1GB/2GB/4GB/8GB

Max is 16GB.

DDR3_B1 512MB/1GB/2GB/4GB/8GB

Dual Channel Memory Installation

Please refer to the following requirements to activate Dual Channel function:

Install memory module of the same density in pairs, shown in the table.

Dual Channel Status DDR3_A1 DDR3_B1

Disabled O X

Disabled X O

Enabled O O

(O means memory installed, X means memory not installed.)

Note: When installing more than one memory module, we recommend to use the same brand

and capacity memory on this motherboard.

2.5 Expansion Slots

Install an Expansion Card

You can install your expansion card by following steps:

1. Read the related expansion card's instruction document before install the

expansion card into the computer.

2. Remove your computer's chassis cover, screws and slot bracket from the

computer.

3. Place a card in the expansion slot and press down on the card until it is

completely seated in the slot.

4. Secure the card’s metal bracket to the chassis back panel with a screw.

5. Replace your computer's chassis cover.

6. Power on the computer, if necessary, change BIOS settings for the

expansion card.

7. Install related driver for the expansion card.
