B75MU3+
39
ESPECIFICAÇÕES
Conector de áud io frontal x1 Suporta a função de áudio no painel frontal
Conector da ventoinha da CPU x1
Alimentação da ventoinha da CPU (com a função
Smart Fan)
Conector da ventoinha do sistema x1 Alimentação da ventoinha do sistema
Conector para limpeza do CMOS x1
Conector USB2.0 x2
Cada conector suporta 2 portas USB2.0 no painel
frontal
Conector USB3.0 x1
Cada conector suporta 2 portas USB3.0 no painel
frontal
Conector de IR do consumidor x1
Conector da para impressora x1 Cada conector suporta 1 Porta para impressora
Porta série x1
Conector de saída S/PD IF x1 Suporta a saída de áudio d igital
Conector de alimentação x1
(24 pinos)
Conector de alimentação x1
(4 p inos)
Entradas/S
aídas no
painel
traseiro
Tec l ado PS /2 x 1
Porta HDMI x1
Porta VGA x1
Porta DVI x1
Porta LAN x1
Porta USB2.0 x2
Porta USB3.0 x2
Tomada de áudio x3
Tamanho
da placa
220 mm (L) X 244 mm (A) ATX
Sistemas
operativos
suportados
Windows XP / Vista / 7
A Biostar reserva-se o direito de adicionar ou
remover suporte para qualquer sistema operativo
com ou sem aviso prévio.
