TZ68K+
49
Especificación
Conector SATA3 X2 Cada conector soporta 1 dispositivos SATA3
Conector SATA2 X4 Cada conector soporta 1 dispositivos SATA2
Conector de p anel f rontal X1 Soporta ins talac iones en el panel frontal
Conector de sonido frontal X1 Soporta funciones de sonido en el panel frontal
Cabecera de ventilador de CPU X1 Fuente de alimentación de ventilador de CPU (con
función Smart Fan)
Cabecera de ventilador de sistema X2 Fuente de alimentación de ventilador de sistema
Cabecera de borrado de CMOS X1
Conector USB2.0 X3 Cada conector soporta 2 puertos USB2.0 frontales
Conector de IR del consumidor X1
Conector Puerto de impresora X1 Cada conector soporta 1 Puerto de impresora
Puerto serie X1
Conector de salida S/PDIF X1 Soporta función de salida de sonido digital
Conector de alimentación X1
(24 patillas)
Conectores
en placa
Conector de alimentación X1
(8 patillas)
Panel
trasero de
E/S
Teclado / Ratón PS/2 X1
Ratón HDMI X1
Puerto VGA X1
Puerto DVI-D X1
Puerto de red local X1
Puerto USB2.0 X2
Puerto USB3.0 X2
Conector de sonido X3
USB3.0 dispositivos (por ASM1042)
USB2.0/USB1.X dispositivos (por Z68)
Ta mañ o d e
la placa
230 mm. (A) X 305 Mm. (H)
Soporte de
sistema
operativo
Windows XP / Vista / 7
Biostar se reserva el derecho de añadir o retirar el
soporte de cualquier SO con o sin aviso previo.
