Motherboard Manual
52
POLISH
SPEC
Procesor
Socket 1155
Procesor Intel Core i7 / i5 / i3 / Pent ium /
Celeron
Obsługa Execute Disable B it / Enhanced Intel
SpeedStep® / Intel Architecture-64 / Extended
Memory 64 Technology / Virtualization Technology /
Hyp er Thread ing
Chipset
Intel Z68
Pamięć
główna
Gniazda DDR3 DIMM x 4
Maks. wielkość pamięci 32GB
Każde gniazdo DIMM obsługuje moduły
512MB/1GB/2GB/4GB/8GB DDR3
Moduł pamięci DDR3 z trybem podwójnego kanału
Obsługa DDR3 1066/1333/1600(OC)
Obsługa DDR3 1866(OC)/2133(OC)/2200(OC)
Brak obsługi R egistered DIMM oraz ECC DIMM
Super I/O
IT8728
Zapewnia najbardziej powszechne funkcje
Super I/O.
Interfejs Low Pin Count
Funkcje kontroli warunków pracy,
Monitor H/W
Kontroler/Monitor prędkości wentylatora
Funkcja ITE "Smart Gu ardian"
SATA 2 & 3
Zintegrowany kontroler Serial ATA
Transfer danych do 3.0 Gb/s / 6.0 Gb/s.
Zgodność ze specyfikacją SATA w wersji 2.0 / 3.0.
LAN
Realtek RTL 8111E
10 / 100 / 1000 Mb/s z automatyczną negocjacją
szybkości
Działanie w trybie połowicznego / pełnego dupleksu
Obsługa
audio HD
ALC892
Obsługa High-Def in ition Aud io
5.1 kanałowe wyjście audio
USB3.0
ASM1042 Cena transferu danych do 600 MB / s
Gniazdo PCI x2
Gniazdo PCI-E Gen2 x16 @ x16 x1
Gniazdo PCI-E Gen2 x16 @ x4 x1
Gniazda
Gniazdo PCI-E Gen2 x 1 x1
