TZ68K+
51
ESPECIFICAÇÕES
Conector SATA3 x2 Cada conector suporta 1 dispositivo SATA3
Conector SATA2 x4 Cada conector suporta 1 dispositivo SATA2
Conector do painel frontal x1 Para suporte de várias funções no painel frontal
Conector de áudio frontal x1 Suporta a função de áud io no painel frontal
Conector da ventoinha da CPU x1
Alimentação da ventoinha da CPU (com a função
Smart Fan)
Conector da ventoinha do sistema x2 Alimentação da ventoinha do sistema
Conector para limpeza do CMOS x1
Conector USB2.0 x3
Cada conector suporta 2 portas USB2.0 no painel
frontal
Conector de IR do consumidor x1
Conector da para impressora x1 Cada conector suporta 1 Porta para impressora
Porta série x1
Conector de saíd a S/PDIF x1 Suporta a saída de áud io d igital
Conector de alimentação x1
(24 pinos)
Conectores
na placa
Conector de alimentação x1
(8 p inos)
Entradas/S
aídas no
painel
traseiro
Teclado / Rato PS/2 x1
Porta HDMI x1
Porta VGA x1
Porta DVI-D x1
Porta LAN x1
Porta USB2.0 x2
Porta USB3.0 x2
Tomada de áudio x3
USB3.0 dispositivos (por ASM1042)
USB2.0/USB1.X dispositivos (por Z68)
Tamanho
da placa
230 mm (L) X 305 mm (A)
Sistemas
operativos
suportados
Windows XP / Vista / 7
A Biostar reserva-se o direito de adicionar ou
remover suporte para qualquer sistema operativo
com ou sem aviso prévio.
