TZ68K+
55
СПЕЦ
Разъём SATA3 x2 Каждый разъём поддерживает 1 устройство SATA3
Разъём SATA2 x4 Каждый разъём поддерживает 1 устройство SATA2
Разъём на лицевой панели x1 Поддержка устройств на лицевой панели
Входной звуковой разъём x1
Поддержка звуко вых функций на лицевой
панели
Контактирующее приспособление
вентилятора центрального процессора x1
Источник питания для вентилятор а центрального
процессора (с функц ией интеллектуального
вентилятора)
Контактирующее приспособление
вентилятора системы x2
Источник питания для вентилятора системы
Открытое контактирующее
приспособление CMOS x1
USB2.0-разъём x3
Каждый разъём поддерживает 2 USB2.0-порта на
лицевой панели
Разъём едока ИКЫЙ x1
Разъём Порт подключения
принтера x1
Каждый разъём поддерживает 1 Порт
подключения принтера
Последовательный порт x1
Разъём вывода для S/PDIF x1 Поддержка вывода цифровой звуковой функц ии
Разъем питания (24 вывод) x1
Встроенны
й разъём
Разъем питания (8 вывод) x1
Задняя
панель
средств
ввода-выв
ода
Клавиатура / Мышь PS /2 x1
Порт HD MI x1
Порт VGA x1
Порт DVI-D x1
Порт LAN x1
USB2.0-порт x2
USB3.0-порт x2
Гнездо для подключения
наушников x3
USB3.0 устройств (по ASM1042)
USB2.0/USB1.X устройств (по Z68)
Размер
панели
230 мм (Ш) X 305 мм (В)
Поддержка
OS
Windows XP / Vista / 7
Biostar сохраняет за собой право добавлять или
удалять средства обеспечения для OS с или без
предварительного уведомления.
