Thank you for purchasing PLANET 12/24-Port Web Smart
PoE Injector Hub,
● POE-1200/POE-1200P2/POE-1200G–12-PortPoEInjector
Hub
● POE-2400/POE-2400P4/POE-2400G–24-PortPoEInjector
Hub
Unless model numberis specied, the term
“PoE Injector
Hub” in the following sections means the series of the
products.
1. Package Content
Upon open the box of the PoE Injector Hub and carefully
unpack it. The box should contain the following items:
● ThePoEInjectorHubx1
● ThisQuickInstallationGuidex1
● User’sManualCDx1
● PowerCordx1
● RubberFeetx4
● Tworack-mountingbracketswithattachmentscrewsx1
If any item is found missing or damaged, please contact
your local reseller for replacement.
2. Requirements
The following equipments are necessary for further
management.
Network cables:
Usestandardnetwork(UTP)cableswithRJ45connectors.
SubscriberPCinstalledwithEthernetNIC(NetworkCard)
Theoperate systemofsubscriberPCthat running Windows
98/ME, NT4.0, 2000/2003/XP/Vista, MAC OS9 or later,
Linux, UNIX or other platform compatible with TCP/IP
protocols.
3. Start Web Management
You can manage the PoE Injector Hub remotely by having
aremotehostwithWeb browser,suchasMicrosoftInternet
Explorer,NetscapeNavigatororMozillaFirefox.
Web Smart PoE Injector Hub
RJ-45/UTP Cable
PC/Workstation
with
IE or Netscape Browser
Please note that the PoE Injector Hub is congured
through an Ethernet connection, make sure the manager
PC must be set on the same IP subnet address, for
example, the default IP address of the PoE Injector Hub is
192.168.0.100 (the factory-default IP address), then the
manager PC should be set at 192.168.0.x (where x is a
number between 1 and 254, except 100), and the default
subnetmaskis255.255.255.0.
Entering default IP address then the Web login screen
appearsinFigure1
DefaultIPAddress:
192.168.0.100
DefaultAccount:admin
DefaultPassword:admin
Note
ThefollowingscreenisbasedonPOE-2400P4.
ForotherPoEInjectorHub,theweb screenwill
thesameasPOE-2400P4.
Figure 1. Web Login Screen of PoE Injector Hub
After entering the user name and password in login screen.
TheWebmainscreenappearsasFigure2.
Figure 2. Web Main Screen of POE-2400P4
Note
For security reason, please change and
memorize the new password after this first
setup.
