All speciﬁcations valid at nominal input voltage, full load and +25°C after warm-up time unless otherwise stated.

Redundancy Modules

TSP-REM Series 90–600 Watt

Output Specifications

Ouput Voltage adjustable range with potentiometer 24 – 27 VDC

Ripple and noise (20 MHz bandwidth) 230 mVp-p typ.

Capacitive load unlimited

General Specifications

Operating temperature –25°C to +70°C max.

derating above +40°C : 1.5 %/K

Storage temperature –25°C to +85°C max.

Temperature coefficient 0.02 %/K

Humidity (non condensing) 5 % to 90 % rel. H max.

Reliability, calculated MTBF at +25°C acc. to IEC 61709 – TSP–REM360 >2 Mio h

– TSP–REM600 >1.9 Mio h

Remote On/Off by ext. contact: contact open = On contact closed = Off

Alarm relay contact 30 VDC / 1.0 A

Redundancy OK signal (Alarm) trigger threshold at 18...22VDC,

contact open one or both

Remote link cable (0.5 m) 2 cables included (order code TSP-JC)

www.tracopower.com/products/tsp-rc-cable.pdf

Degree of protection IP 20 (IEC/EN 60529)

Isolation according to IEC/EN 60950-1, UL 60950-1, UL 508

Altitude during operation tba.

Safety standard IEC/EN 60950-1, UL 60950-, EN60079, UL60079, UL508

IEC/EN 61010-1, IEC/EN 61010-2-201

Safety approvals UL 508

II3G Ex nA nC llC T4 Gc

– CSA UL60079-15-2 class 1, division 2

– CB test certificate IEC 60950-1 (SIQ for EN)

IEC/EN 61010-1, IEC/EN 61010-2-201

– Certification documents www.tracopower.com/overview/tsp

Electromagnetic compatibility in correspondence to connected units

(no internal switching device)

Environment – Vibration acc. IEC 60068-2-6; 3 axis, sine sweep, 10 – 55 Hz, 1 g, 1 oct/min

– Shock acc. IEC 60068-2-27 3 axis, 15 g half sine, 11 ms

Enclosure material aluminium (chassis) / stainless steel (cover)

Mounting – DIN-rail mounting for DIN-rails as per EN 50022-35x15/7.5

(snap-on with self-locking spring)

– Wall mounting (option) with wall mounting bracket - see page 4

Connection detachable screw terminals (plugs included)

2 terminals per output

Installation instructions www.tracopower.com/overview/tsp
