![Biostar H61MU3 Версия 6.x [38/45] Motherboard manual](/views2/1709568/page38/bg26.png)
Motherboard Manual
36
POLISH
TH61MU3 / H61 MU3 H61 MH / H61ML
Procesor
Socket 1155
Procesor Intel Core i7 / i5 / i3 / Pentium
Obsługa Execute Dis able B it / Enhanced Intel
SpeedStep® / Intel Architecture-64 / Extended
Memory 64 Technology / Virtualization
Technology
Socket 1155
Procesor Intel Core i7 / i5 / i3 / Pentium
Obsługa Execute Dis able B it / Enhanced Intel
SpeedStep® / Intel Architecture-64 / Extended
Memory 64 Technology / Virtualization
Technology
Chipset
Intel H61 Intel H61
Pamięć
główna
Gniazda DDR3 DIMM x 2
Każde gniazdo DIMM obsługuje moduły 512MB
/ 1GB / 2GB / 4GB
Maks. wielkość pamięci 8GB Moduł pamięci
DDR3 z trybem podwójnego kanału
Obsługa DDR3 1333/1066
Brak obsługi Registered DIMM oraz ECC DIMM
Gniazda DDR3 DIMM x 2
Każde gniazdo DIMM obsługuje moduły 512MB
/ 1GB / 2GB / 4GB
Maks. wielkość pamięci 8GB Moduł pamięci
DDR3 z trybem podwójnego kanału
Obsługa DDR3 1333/1066
Brak obsługi Registered DIMM oraz ECC DIMM
Super I/O
ITE 8728
Zapewnia najbardziej powszechne funkcje
Super I/O.
Interfejs Low Pin Count
Funkcje kontroli warunków pracy,
Monitor H/W
Kontroler/Monitor prędkości wentylatora
Funkcja ITE "Smart Guard ian"
ITE 8728
Zapewnia najbardziej powszechne funkcje
Super I/O.
Interfejs Low Pin Count
Funkcje kontroli warunków pracy,
Monitor H/W
Kontroler/Monitor prędkości wentylatora
Funkcja ITE "Smart Guard ian"
SATA 2
Zintegrowany kontroler Serial ATA
Transfer danych do 3.0 Gb/s.
Zgodność ze specyfikacją SATA w wersji 2.0.
Zintegrowany kontroler Serial ATA
Transfer danych do 3.0 Gb/s.
Zgodność ze specyfikacją SATA w wersji 2.0.
LAN
Realtek RTL8111E
10 / 100 / 1000 Mb/s z automatyczną
negocjacją szybkości
Realtek RTL8111E (H61MH)
10 / 100 / 1000 Mb/s z automatyczną
negocjacją szybkości
Realtek RTL8105E (H61ML)
10 / 100 Mb/s z automatyczną negocjacją
szybkości
Obsługa
audio HD
ALC662
Obsługa High-Def inition Aud io
5.1 kanałowe wyjście audio
ALC662
Obsługa High-Def inition Aud io
5.1 kanałowe wyjście audio
USB3.0
Asmedia ASM1042
Gniazdo PCI Express Gen2 x16 x1 Gniazdo PCI Express Gen2 x16 x1
Gniazdo PCI Express Gen2 x1 x1 Gniazdo PCI Express Gen2 x1 x1
Gniazda
Gniazdo PCI x2 Gniazdo PCI x2
