Motherboard Manual
4
KBMS1
DVI1
VGA1
USB1
RJ45USB1
AUDIO1
ATXPWR2
F_AUDIO1
BAT1
LAN
CODEC
Super
I/O
PEX1_1
PEX1_2
PEX16_1
J_COM1
F_USB1
F_USB2 PAN EL1
J_ PRINT1
SATA2
SATA1
SATA3 SATA4
JCMOS 1
SYS_FAN1
ATXPWR1
CPU_FAN1
DDR3_A1
DDR3_B1
Socket 1155
CPU1
H61
BIOS
(H61MGC)
Note: ■ represents the 1
st
pin.
