Motherboard Manual
4
1.5 MOTHERBOARD LAYOUT
USBKB1
HDMI1
VGA1
DVI1
RJ45USB1
AUDIO1
JUSBV1
F_AUDIO1
LAN
ATXPWR2
CODEC
SYS_FAN2
PEX 16_1
PEX1_1
PEX 16_2
PCI1
PCI2
Super
I/O
JSPDIFOUT1
J_PRINT1
J_COM1
CIR1
JUSBV2
F_USB 3 F_USB2 F_USB1
PAN EL1
SYS_FAN1
JCMOS1
SATA5
SATA4
SATA2
SATA3
SATA1
SATA6
BIOS
ATXPWR1
DDR3_B2
DDR3_B1
DDR3_A2
DDR3_A1
CPU_FAN1
H55
Socket 1156
CPU1
BAT1
Note: ■ represents the 1
st
pin.
