T41 HD BIOS Manual
30
PCIE Frequency Setting
This item allows you to select the PCIE clock control
Options: 100 (Default) / Min=100; Max=150
FS B( Bsel) To NorthBridge Latch
This item allows you to select the FSB Frequency.
Options: Auto (Default) / FSB 800 / FSB 1066 / FSB 1333
DRAM Frequency
This item allows you to control the Memory Clock.
Options: Auto (Default) / DDR2 440Mhz / DDR2 528Mhz / DDR2 550Mhz /
DDR2 660Mhz / DDR2 733Mhz / DDR2 880Mhz (Differed by CPU)
ALL Voltage Configuration
BIOS SETUP UTILITY
T-Series
vxx.xx (C)Copyright 198 5-200x, American Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
Voltage Configurat ion
CPU Voltage [Default ]
CPU GTL Ref Voltag e [0.63*VTT]
FSB Voltage [Default ]
Chipset Voltage [Default ]
MCH GTL Ref Voltag e [0.63*VTT]
Memory Voltage [Default ]
CPU Voltage Control
CPU Voltage
This item allows you to select CPU Voltage Control.
Options: Auto (Default) / -0.050V ~ +0.1300V
CPU GTL Ref Voltage
This item allows you to select CPU GTL Ref Voltage Control.
Options: 0.63*VTT (Default) / 0.67*VTT / 0.61*VTT / 0.58*VTT
