TP43E3 XE BIOS Manual
10
Execute-Disable Bit Capability
This item allows you to configure the Execute Disabled Bit function, which protects
your system from buffer overflow attacks.
Options: Enabled (Default) / Disabled
Core Multi-Processing
This item allows multi-processing function for multi-core processors.
Options: Enabled (Default) / Disabled
SuperIO Conf iguratio n
BIOS SETUP UTILITY
Advanced
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
Allows BIOS to Enable
or Disable Floppy
Controller
Configure Super IO Chipset
OnBoard Floppy Controller [Enabled]
Serial Port1 Address [3F8/IRQ4]
Keyboard PowerOn [Disabled]
Mouse PowerOn [Disabled]
Restore on AC Power Loss by IO[Power Off]
Onboard Floppy Controller
Select enabled if your system has a floppy disk controller (FDC) installed on the
system board and you wish to use it. If you installed another FDC or the system uses
no floppy drive, select disabled in this field.
Options: Enabled (Default) / Disabled
Serial Port1 Address
Select an address and corresponding interrupt for the first and second serial ports.
Options: 3F8/IRQ4 (Default) / 2F8/IRQ3 / 3E8/IRQ4 / 2E8/IRQ3 / Disabled
