TP45 HP/TP43 HP BIOS Manual
10
Core Multi-Processing
This item allows multi-processing function for multi-core processors.
Options: Enabled (Default) / Disabled
Intel(R) C-STATE Tech
This item allows you to control the C-State power management functions of the
processor.
Options: Enabled (Default) / Disabled
SuperIO Conf iguratio n
BIOS SETU P UTILITY
Advan ced
vxx .xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
Allows BIOS to Enable
or Disable Floppy
Controller
Configure Supe r IO Chipset
Onboard Floppy Controller [Enabled]
Serial Port1 A ddress [3F8/IRQ4]
Keyboard Power On [Disabled]
Mouse PowerOn [Disabled]
Restore on AC Power Loss by IO[Power Off]
Parallel Port Address [378]
Parallel Por t Mode [Normal]
Parallel Por t IRQ [IRQ7]
Onboard Floppy Controller
Select enabled if your system has a floppy disk controller (FDC) installed on the
system board and you wish to use it. If you installed another FDC or the system uses
no floppy drive, select disabled in this field.
Options: Enabled (Default) / Disabled
Serial Port1 Address
Select an address and corresponding interrupt for the first and second serial ports.
Options: 3F8/IRQ4 (Default) / 2F8/IRQ3 / 3E8/IRQ4 / 2E8/IRQ3 / Auto / Disabled
