Planet GT-706B60 [14/19] Chapter 10 product specification

Chapter 10 PRODUCT SPECIFICATION

The GT-70X comes with the following standard features:

Standards:

IEEE 802.3ab 1000Base-T

IEEE 802.3z 1000Base-SX/LX

Duplex Mode: Full Duplex Mode

Transfer rate 1000Mbps

Media

Interface:

RJ-45, SC, single SC(WDM)

LED

indicators:

PWR, FDX, Fiber/LNK/ACT, TP/LNK/ACT

Cable

1000Base-T:

4 pair Cat. 5, EIA/TIA-568 100-ohm screened

twisted-pair (STP), up to 100m

1000Base-SX :

62.5/125μm multi-mode ber optic cable,

up to 220m

50/125μm multi-mode ber optic cable, up to

550m

1000Base-LX :

9/125μm single-mode ber optic cable, up to

10km/15/60km

Dimensions 26 x 70 x 97mm (H x W x D)

Power External power adaptor 5V 2A max.

EMI

Compatibility:

FCC Class A, CE Certification Class A

Temperature:

Storage: -40°C ~ 70°C

Operating: 0°C ~ 50°C

Humidity: 5% ~90% non-condensing



Notice:

Connecting to the Gigabit Ethernet products, please refer to the device’s

Technical Manual.
