User Guide

TF650i Ultra-A7

Motherboard for

Intel Processor

Installation and Configuration

Содержание

User guide 1
Table of contents 2
List of figures 7
Before you begin 8
Parts not in the kit 8
Intentions of the kit 9
Comprehensive overclocking tools 11
Features 11
Guaranteed fsb speeds 11
High speed memory 11
Introduction 11
Ultimate overclocking 11
Dualddr2 memory architecture 12
Multiple disk setup 12
Nv bios 12
Nvidia mediashield storage 12
Nvidia ntune utility 12
True x16 pci express support 12
Bootable multidisk array 13
Diskalert system 13
Networking with nvidia nforce 13
Nvidia firstpacket technology 13
Nvidia native gigabit ethernet 13
Raid morphing 13
High definition audio hda 14
Motherboard specifications 15
Tf650i ultra a7 motherboard 17
Figure 1 tf650i ultra a7 motherboard layout 18
Installing and configuring the tf650i ultra a7 motherboard 18
Figure 2 chassis backpanel connectors 19
Hardware installation 20
Safety instructions 20
Installing the cpu 21
Preparing the motherboard 21
Installing memory dimms 22
Installing the cpu fan 22
Installing the i o shield 23
Installing the motherboard 23
Securing the motherboard into the chassis 23
Connecting cables and setting switches 24
Figure 3 pwr1 motherboard connector 25
Pin atx power 25
Power connections 25
Table 1 pwr1 pin assignments 25
Connecting ide hard disk drives 26
Connecting serial ata cables 26
Pin atx 12v power 26
Attach the front panel power led cable to these two pins of the connector the power led indicates the system s status when the system is in s0 status the led is on when the system is in s1 s3 s4 s5 status the led is off 28
Attach the hard disk drive indicator led cable to these two pins the hdd indicator led indicates the activity status of the hard disks 28
Attach the power button cable from the case to these two pins pressing the power button on the front panel turns the system on off rather than using the power supply button 28
Attach the reset switch cable from the front panel of the case to these two pins the system restarts when the 28
Connecting internal headers 28
Front panel header 28
Switch is pressed 28
The front panel header on this motherboard is one connector used to connect the following four cables 28
Hardware installation 29
Hd_led 29
No connect 29
Pin signal in out description 29
Pwrled 29
Table 2 front panel header pins 29
Connector pin signal pin signal 30
Installing and configuring the tf650i ultra a7 motherboard 30
Secure the bracket to either the front or rear panel of your chassis not all chassis are equipped with the front panel option 2 connect the two ends of the cables to the usb 2 headers on the motherboard 30
Table 3 usb 2 header pins 30
This motherboard contains four 4 usb 2 ports that are exposed on the rear panel of the chassis the motherboard also contains two 10 pin internal header connectors onboard that can be used to connect an optional external bracket containing four 4 more usb 2 ports 30
Usb headers 30
Fan connections 31
Fdd connector 31
Expansion slots 32
Figure 4 expansion slots 32
Pci slots 32
Clear cmos jumper clr_cmos 33
Jumper settings 33
Pci express x1 slot 33
Pci express x16 slots 33
Advanced bios features 34
Advanced chipset features 34
Configuring the bios 34
Enter bios setup 34
Integrated peripherals 34
Main menu 34
Pnp pci configurations 34
Power management setup 34
Standard cmos features 34
System monitor 34
This section discusses how to change the system settings through the bios setup menus detailed descriptions of the bios parameters are also provided 34
This section includes the following information 34
Enter bios setup 35
Key when the following message briefly displays at the bottom of the screen during the power on self test post 35
Keys to scroll through the options or press 35
Main menu 35
Power on the computer 2 press the 35
Pressing 35
Takes you to the phoenix award bios cmos setup utility 35
The bios is the communication bridge between hardware and software correctly setting the bios parameters is critical to maintain optimal system performance 35
The main menu allows you to select from the list of setup functions and two exit choices use the 35
To display the associated submenu use the arrow keys to position the selector in the option you choose to go back to the previous menu press 35
Use the following procedure to verify change bios settings 35
Figure 5 bios cmos setup utility main menu 36
Corresponds to the option highlighted 38
Data in blue is non changeable and data in a red box is highlighted for selection 38
Figure 6 standard cmos features menu 38
Installing and configuring the tf650i ultra a7 motherboard 38
Item hel 38
Keys to scroll through the options or press 38
Note note that all data in white is for information only data in yellow is changeable 38
Page dow 38
Page up 38
Standard cmos features menu 38
The information shown in 38
The standard cmos features menu is used to configure the standard cmos information such as the date time hdd model and so on use the 38
To display the sub menu use the arrow keys to position the selector in the option you choose to go back to the previous menu press 38
Configuring the bios 39
Date and time 39
Date mm dd yy sat jul 01 2006 time hh mm ss 14 48 43 39
Hour minute secon 39
Ide channel and sata channel 39
Keys to scroll through dates and times note that the weekday sun through sat cannot be changed this field changes to correspond to the date you enter note that the hour value is shown in a 24 hour clock format time is represented as 39
Page dow 39
Page up 39
Press enter to display ide channel sub menu 39
Press enter to display sata channel sub menu 39
To display the ide sata sub menu 39
Use these functions to detect and configure the individual ide and sata channels select a channel and pres 39
Using the arrow keys position the cursor over the month day and year use the 39
Drive a 41
Halt on 41
Memory 42
Access the advanced bios features menu from the cmos utility setup screen use the 43
Advanced bios features 43
Configuring the bios 43
Data in blue is non changeable and data in a red box is highlighted for selection 43
Figure 7 advanced bios features menu 43
Keys to scroll through the options or press 43
Note note that all data in white is for information only data in yellow is changeable 43
Note the options that have associated sub menus are designated by a which 43
Page dow 43
Page up 43
Precedes the option press 43
To display the sub menu use the arrow keys to position the selector in the option you choose to go back to the previous menu press 43
To display the sub menus 43
Cpu internal cache 44
Hard disk boot priority 44
Network boot priority 44
Removable device priority 44
Boot other device 45
Boot up numlock status 45
First second third boot device 45
Quick power on self test 45
Apic mode 46
Full screen logo show 46
Mps version control for os 46
Security option 46
Advanced chipset feature 47
Advanced chipset features 47
Configuring the bios 47
Figure 8 advanced chipset features 47
From the cmos setup utility menu and press 47
Select 47
To display the functions of the advanced chipset functions menu 47
Data in blue is non changeable and data in a red box is highlighted for selection 48
Figure 9 system clocks menu 48
From the advanced chipset features menu and press 48
Installing and configuring the tf650i ultra a7 motherboard 48
Note note that all data in white is for information only data in yellow is changeable 48
Select 48
System clock 48
System clocks 48
To display the system clocks menu from this menu you are able to specify frequency settings ht multipliers and spread spectrum settings note that in figure 9 all of the options are listed on the actual bios screen you will need to scroll down to see all the options 48
Frequency settings 49
Ht multiplier 50
Spread spectrum 50
Changes proportionally 51
Cpu freq mh 51
Figure 10 fsb memory config menu 51
From the advanced chipset features menu and press 51
Fsb and memory clock mode use the 51
Fsb memory config 51
Fsb qdr mh 51
Is changed to editable and the fsb speed can be entered manually as the fsb speed is changed 51
Keys to scroll through the fsb and memory clock mode options the options are auto this is the optimal setting since it sets the fsb and memory speeds automatically 51
Linked when link is selected 51
Select 51
To display the fsb memory config menu this menu provides the means to set fsb and memory timing 51
Actual fsb qdr 52
Actual mem ddr 52
Are changed to editable and the fsb and memory speeds can be entered manually as the fsb speed is changed 52
Changes proportionally 52
Cpu freq mh 52
Fsb qdr mhz 52
Fsb qdr mhz use the 52
Installing and configuring the tf650i ultra a7 motherboard 52
Keys to scroll through new values for the cpu fsb frequency or type in a new value note that the 52
Keys to scroll through new values for the memory frequency or type in a new value note that the 52
Mem ddr mhz 52
Mem ddr mhz use the 52
Memory timing setting press 52
Reflects the actual frequency that takes effect on a reboot 52
Reflects the actual frequency that takes effect when the system reboots 52
To display the memory timing setting menu use this menu to set optimal timings or to manually enter timings 52
Unlinked when unlink is selected 52
Configuring the bios 53
Keys to select 53
Optimal 53
Optimal prohibits you from manually setting any timing all timing is set for optimal performance 53
Optimal use the 53
Page dow 53
Page up 53
Cas latency options are 1 through 6 54
Command per cloc 54
Expert use the 54
Installing and configuring the tf650i ultra a7 motherboard 54
Keys to select 54
Page dow 54
Page up 54
Ras to cas delay for read write commands to the same bank options are 1 through 7 54
Ras to ras delay of different banks options are 1 through 15 54
Ras to ras or auto refresh time of the same bank options are 1 through 31 54
Row precharge time this is the precharge to active or auto to refresh of the same bank options are 1 through 7 54
The write recovery time options are 2 through 7 54
This is the command timing setting on a per clock unit basis options are 1t and 2t 54
This is the dram refresh rate options are 54
This is the minimum ras active time options are 1 through 31 54
This is the minimum write to read delay with the same chip selected options are 1 through 10 54
When expert is selected all timing categories are enabled for manual input note that you should set the value to optimal to use the manufacturers recommended values 54
Configuring the bios 55
Cpu configuratio 55
Cpu configuration 55
Cpu thermal control use this function to enable or disable tm1 and tm2 support the options are disable disable support for tm1 and tm2 55
Figure 11 cpu configuration menu 55
From the advanced chipset features menu and press 55
Limit cpuid maxval use this function to enable the set limit of the cpuid maxval to 3 set to disable for win xp 55
Select 55
Tm1 only the cpu is thermally throttled by cutting active processor clock cycles 55
Tm2 only thermal throttling is achieved by reducing the cpu multiplier and cpu core voltage 55
To display the cpu configuration menu 55
C1e enhanced halt state e nabled this function reduces the cpu power consumption when the cpu is idle idle occurs when the operating system issues a halt instruction 56
Cpu core 1 this function allows you to enable or disable cpu core 56
Execute disable bit when this function is disabled it forces the xd feature flag to always return to zero 0 56
Figure 12 system voltages menu 56
From the advanced chipset features menu and press 56
Installing and configuring the tf650i ultra a7 motherboard 56
Select 56
System voltage 56
System voltages 56
Tm1 tm2 enables support for both tm1 and tm2 56
To display the system voltages menu 56
Virtualization technology when this function is enabled it allows a vmm to utilize the additional hardware capabilities provided by intel virtualization technology 56
For all settings press 58
Function 58
Installing and configuring the tf650i ultra a7 motherboard 58
Load timing voltage set 58
Nvmem memory test 58
Save timing voltage se 58
There are four profile options that can be loaded the default setting is 58
This function defines whether you run the nvidia memory testing module during post the options are fast medium slow and disable 58
This function loads the system voltages and timing settings that were defined in the system voltages menu you can set up to four profile settings using the 58
To see the options 58
Hpet function 59
Nvidia gpu ex 59
Save timing voltage set 59
System bios cacheable 59
Figure 13 integrated peripherals menu 60
From the cmos setup utility menu and press 60
Installing and configuring the tf650i ultra a7 motherboard 60
Integrated peripheral 60
Integrated peripherals menu 60
Select 60
To display the integrated peripherals menu 60
And cannot be changed 61
Configuring the bios 61
Disabled 61
Enable all 61
Enabled 61
Ide dma transfer access use this function to enable or disable ide dma transfer access 61
Ide function setup 61
Ide prefetch mod 61
Ide prefetch mode use this function to enable or disable the 61
Is set to 61
Mode 1 61
Onchip ide channel 61
Onchip ide channel0 use this function to enable or disable the onchip ide channel0 when disabled the primary master slave functions are changed to 61
Primary master slave pio when 61
Primary master slave udma when 61
Sata 0 61
Sata 0 1 61
Serial ata controller this function allows you to enable specific sata controllers enable all controllers or disable all controllers the options available are 61
Through 61
To display the ide function setup menu 61
You can disable the primary master and slave udma or set it to 61
You can select a mode for the primary master and slave pio select from 61
All sata functions are changed to 62
And cannot be changed 62
And cannot be changed versions that can be selected are 62
Disable 62
Disabled 62
Enable 62
Enabled 62
Installing and configuring the tf650i ultra a7 motherboard 62
Is set to 62
Onchip usb use this function to enable specific versions of the usb or disable the onchip usb when the onchip usb is set to 62
Raid config 62
Raid enabl 62
Raid enable use this function to enable or disable raid when raid is set to 62
Sata x primary secondary when 62
The keyboard and mouse support functions are set to 62
To display the raid config menu 62
To display the usb config menu 62
Usb config 62
Usb keyboard mouse support use these function to enable or disable the onchip wsb support of the keyboard and or mouse 62
You can enable or disable the various sata functions 62
Hd audio 63
Ide hdd block mode 63
Mac config 63
Onboard fdc controller 63
Onboard serial port 1 63
Acpi function 64
Acpi suspend type 64
Figure 14 power management setup menu 64
From the cmos setup utility menu and press 64
Power management setup menu 64
Select 64
This function on the power management setup menu allows you to enable or disable the acpi function 64
This function on the power management setup menu allows you to select an acpi suspend type types to select from are 64
To display the power management setup menu 64
Power on by alarm 65
Power on function 65
Soft off by pbnt 65
Wol pme from soft off 65
Any key 66
Figure 15 pnp pci configuration menu 66
From the cmos setup utility menu and press 66
Function is enabled so that you must select a keyboard key as the hot key to select a hot key use 66
Hot key 66
Hot key power o 66
Hot key power on when 66
Is selected the 66
Mouse left 66
Mouse right 66
Pnp pci configuration menu 66
Select 66
Though 66
To display the pnp pci configuration menu 66
Init display first 67
Reset configuration data 67
Resources controlled by 67
Irq resources 68
Keys to go up and down the list of sizes 68
Keys to scroll through sizes or enter the number using the keyboard numbers or use the 68
Manual 68
Maximum payload size 68
Pci vga palette snoop 68
Resources controlled b 68
This function on the pnp pci configuration menu allows you to enable or disable the palette snoop function 68
This function on the pnp pci configuration menu allows you to set the maximum tlp payload size in bytes for the pci express devices use the 68
To enable this field for input set 68
To see options 68
Use legacy isa for devices compliant with the original pc at bus specification use pci isa pnp for devices compliant with the plug and play standard whether designed for pci or isa bus architecture 68
With this field enabled press 68
All of the values shown in 69
Are dynamic and change as the speed and voltages of the various components change with system usage 69
Configuring the bios 69
Figure 16 system monitor menu 69
From the cmos setup utility menu and press 69
Select 69
System monito 69
System monitor menu 69
To display the system monitor menu 69
And then enter the speed from 0 to 100 70
Dynamic fan control 70
Installing and configuring the tf650i ultra a7 motherboard 70
Manual 70
Set the desired speed for the aux nforce and chassis fans from 0 to 100 the system defaults to 100 70
Smartfan 70
To display the dynamic fan control menu 70
Use this menu to control the speed of the various fans on the motherboard set cpu fan speed to 70
When you want the speed of the fans automatically controlled based on temperature to set the fan speed to a constant rate select 70

Biostar TF650i Ultra-A7 Руководство пользователя онлайн

Содержание

Похожие устройства
