P4M900-M7 FE/P4M890-M7 FE
31
P4M900-M7 FE P4M890-M7 FE
LAN PHY
Realtek RTL 8201CL PHY
Negoziaz ione automatica 10 / 10 0 Mb /s
Capacità Half / Full Duplex
Realtek RTL 8201CL PHY
Negoziazione automatic a 10 / 10 0 Mb /s
Capacità Half / Full Duplex
Codec
audio
ALC662
Supporto audio High-Definition (HD)
Uscita audio 5.1 canali
ALC662
Supporto audio High-Definition (HD)
Uscita audio 5.1 canali
Alloggio PCI x2 Alloggio PCI x2
Alloggio PCI Ex press x16 x1 Alloggio PCI Ex press x1 6 x1
Alloggi
Alloggio PCI Ex press x1 x1 Alloggio PCI Ex press x1 x1
Connettore flo ppy x1 Connettore flo ppy x1
Connettore Porta s tampa nte x1 Connettore Porta stampa nte x1
Connettore IDE x2 Connettore IDE x2
Connettore SATA x2 Connettore SATA x2
Connettore pa nnello fro ntale x1 Connettore pa nnello fro ntale x1
Connettore audio frontale x1 Connettore audio frontale x1
Connettore CD-in x1 Connettore CD-in x1
Collettore ventolina CPU x1 Collettore ventolina CPU x1
Collettore ventolina sistema x1 Collettore ventolina sistema x1
Collettore cancellazione CMOS x1 Collettore cancellazione CMOS x1
Connettore USB x2 Connettore USB x2
Connettore alimentazione x1
(24 pin)
Connettore alimentazione x1
(24 pin)
Connettori
su scheda
Connettore alimentazione x1
(4 pi n)
Connettore alimentazione x1
(4 pi n)
I/O
pannello
posteriore
Ta s t i e r a P S / 2 x 1
Mouse PS/2 x1
Porta seriale x1
Porta VGA x1
Porta LAN x1
Porta USB x4
Connettore au dio x3
Ta s t i e r a P S / 2 x 1
Mouse PS/2 x1
Porta seriale x1
Porta VGA x1
Porta LAN x1
Porta USB x4
Connettore au dio x3
Dimension
i scheda
190 mm (lar ghezza) x 244 mm (altezza) 190 mm (lar ghezza) x 244 mm (altezza)
Caratterist
iche
speciali
Supporto RAID 0 / 1 Supporto RAID 0 / 1
Sistemi
operativi
supportati
Windows 2K / XP / VISTA
Biostar si riserva il diritto di aggiungere o
rimuovere il supporto di qualsiasi sistema
operativo se nza pre avviso.
Windows 2K / XP
Biostar si riserva il diritto di aggiungere o
rimuovere il supporto di qualsiasi sistema
operativo se nza pre avviso.
