![Biostar NM70I-1037U Версия 6.x [31/36] Italian](/views2/1710699/page31/bg1f.png)
NM70I-847/NM70I-807/NM70I-1007U/NM70I-1037U
29
Italian
Specificazioni
Supporto
processore
NM70I-847: Intel® Celeron® Processor 847 (Dual Core 1.1GHz)
NM70I-807: Intel® Celeron® Processor 807 (Single Core 1.5GHz)
NM70I-1007U: Intel® Celeron® Processor 1007U (Dual Core 1.5 GHz)
NM70I-1037U: Intel® Celeron® Processor 1037U (Dual Core 1.8 GHz)
Tipo scheda INTEL NM70
Memoria
Supporta DDR3 1066/ 1333 Doppio Canale (NM70I-847 & NM70I-807)
Supporta DDR3 1333/ 1600 Doppio Canale (NM70I-1007U & NM70I-1037U)
2 x DDR3 DIMM Slot di Memoria Supporta fino a 16 GB Memoria
Ogni DIMM supporta non-ECC 512MB/ 1/ 2/ 4/ 8 GB DDR3 moduli
* Si prega di consultare
www.biostar.com.tw per la lista di supporto del memoria.
Memorizzazione
Connettore 1x SATA 6Gb/s, Connettore 3x SATA 3Gb/s
Supporta nativo IDE & AHCI modo
Catena
Realtek RTL 8111F
10/ 100/ 1000 Mb auto negoziazione, capacita di duplex Meta / Completo
Codec Audio
ALC662
Canali Audio di Alta Definizione 5.1
USB Slot 8x USB 2.0 (4 nei ingressi/ uscite posteriore e 4 da distributori interni)
Slot di espansione Slot 1x PCIe 2.0 x16 (x8)
Ingressi/ Uscite
Posteriore
Mouse 1x PS/2
Tastiera 1x PS/2
Slot 1x HDMI
Slot 1x VGA
Slot 1x LAN
Slot 4x USB 2.0
Jack audio 3x
Ingressi/ Uscite
Interni
Connettore 1x SATA 6.0Gb/s
Connettore 3x SATA 3.0Gb/s
Distributore 2x USB 2.0(ogni distributore supporta 2 slot USB 2.0)
Connettore con 4 pin x1
Connettore con 24 pin x1
Connettore Ventilatore processore x1
Connettore Ventilatore Sistema x1
Distributore Pannello Frontale x1
Distributore Audio Frontale x1
Distributore CMOS Diretto x1
Distributore Slot Stampante x1
Distributore Slot Serie x1
Connettore esterno S/PDIF x1
Fattore di Forma Fattore di Forma mini-ITX, 170 mm x 170 mm
Supporto SO
Windows XP / Vista / 7 / 8
Biostar si riserva il diritto di aggiungere o ritirare il supporto per qualsiasi SO con o senza
preavviso
.
