Especificações
Suporte
Processador
J1800MH2: Intel® Celeron® J1800 processor
J1900MH2: Intel® Celeron® J1900 processor
J2900MH2: Intel® Pentium® J2900 processor
N2940MH2: Intel® Celeron® N2940 processor
Memória
Suporta DDR3L 1333 Canal Duplo (1.35V/1.5V)
2 x DDR3L DIMM Slot de memória Suporta até 16 GB Memória
Cada DIMM suporta non-ECC 512MB/ 1/ 2/ 4/ 8 GB DDR3L módulo
* Por favor consulte www.biostar.com.tw
para obter uma lista de suporte do
memória.
Armazenamento Conector 2x SATA 3Gb/s,Suporta nativo IDE & AHCI modo
LAN
Realtek RTL 8111G
10/ 100/ 1000 Mb auto negociação, capacidade duplex Metade / Cheio
Codec de Audio
ALC662
Canais de Áudio de Alta Definição 5.1
USB
Porta 6x USB 2.0 (2 nas entradas/saídas traseiras e 4 pelos Dispositivos
internos)
Porta 1x USB 3.0 (1 nas entradas/saídas traseiras)
Slots de
expansão
Porta 1x PCIe 2.0 x16 (@ x1 speed)
Porta 2x PCIe x1
Entradas/Saídas
no painel
traseiro
Mouse 1x PS/2
Teclado 1x PS/2
Porta 1x HDMI
Porta 1x VGA
Porta 1x LAN
Porta 1x USB 3.0
Porta 2x USB 2.0
Soquete audio 3x
Conectores na
placa
Conector 2x SATA 3.0Gb/s
Dispositivo 2x USB 2.0 (cada Dispositivo suporta 2 portas USB 2.0)
Conector de 4 pinos x1
Conector de 24 pinos x1
Conector de Ventoinha Sistema x2
Dispositivo Painel Frontal x1
Dispositivo de Audio Frontal x1
Dispositivo CMOS Direct x1
Dispositivo Porta Impressora x1
Dispositivo Porta Série x1
Fator de Fôrma Fator de Fôrma Micro-ATX, 226 mm x 188 mm
Suporte OS
Windows 7 / 8 / 8.1
Biostar reserva seu direito de adicionar ou retirar o suporte para qualquer OS
com ou sem notificação.
