Troubleshooting by Remote Controller Si39-302
152 Troubleshooting
Malfunction
code
Operation
lamp
Inspection
display
Unit No. Malfunction contents Page
Referred
Indoor
Unit
A0 999Error of external protection device 156
A1 999PC board defect, E
2
PROM defect 157
A3 999Malfunction of drain level control system (33H) 158
A6 999Fan motor (MF) lock, overload 160
A7 879Malfunction of swing flap motor (MA) 161
A9 999Malfunction of moving part of electronic expansion
valve (20E)
163
AF 879Drain level about limit 165
AH 879Malfunction of air filter maintenance —
AJ 999Malfunction of capacity setting 166
C4 999Malfunction of thermistor (R2T) for heat exchange
(loose connection, disconnection, short circuit,
failure)
167
C5 999Malfunction of thermistor (R3T) for gas pipes (loose
connection, disconnection, short circuit, failure)
168
C9 999Malfunction of thermistor (R1T) for air inlet (loose
connection, disconnection, short circuit, failure)
169
CJ 888Malfunction of thermostat sensor in remote controller 170
Outdoor
Unit
E1 999PC board defect 171
E3 999Actuation of high pressure switch 172
E4 999Actuation of low pressure sensor 173
E5 999Compressor motor lock 174
E6 999Standard compressor lock or over current 175
E7 999Malfunction of outdoor unit fan motor 176
E9 999Malfunction of moving part of electronic expansion
valve (Y1E~3E)
178
F3 999Abnormal discharge pipe temperature 180
F6 999Refrigerant overcharged 181
H3 879Malfunction of High pressure switch —
H4 999Actuation of Low pressure switch —
H7 999Abnormal outdoor fan motor signal 182
H9 999Malfunction of thermistor (R1T) for outdoor air (loose
connection, disconnection, short circuit, failure)
183
J2 999Current sensor malfunction 184
J3 999Malfunction of discharge pipe thermistor (R31~33T)
(loose connection, disconnection, short circuit,
failure)
185
J5 999Malfunction of thermistor (R2T) for suction pipe
(loose connection, disconnection, short circuit,
failure)
186
Outdoor
Unit
J6 999Malfunction of thermistor (R4T) for heat exchanger
(loose connection, disconnection, short circuit,
failure)
187
J7 999Malfunction of header thermistor —
J8 999Malfunction of thermistor (R7T) for oil equalizing pipe.
(loose connection, disconnection, short circuit,
failure)
—
J9 999Malfunction of receiver gas pipe thermistor (R5T) 188
JA 999Malfunction of discharge pipe pressure sensor 189
JC 999Malfunction of suction pipe pressure sensor 190
L0 999Inverter system error —
L4 999Malfunction of inverter radiating fin temperature rise 191
L5 999Inverter compressor motor grounding, short circuit 192
L6 999Compressor motor coil grounding on short circuit —
L8 999Inverter current abnormal 193
L9 999Inverter start up error 194
