Si39-302 Special Control
Function 77
3.3 Defrosting Operation
* In the case of multi-outdoor-unit system,
Master unit: Performs the operations listed in the table above.
Slave units: Operating units perform the operations listed in the table above.
Non-operating units perform the operations listed in the table above from the Defrost operation.
(Non-operating unit stops during “Defrost preparation operation”.)
* Actuators are based on RXYQ16M.
<Defrost starting condition>
Defrost operation is started when the outdoor heat exchanger temperature becomes lower than deicer temperature.
Defrost operation is conducted once in max. 2 hours.
Outdoor unit actuator
Defrost preparation
operation
Defrost operation Post Defrost operation
Compressor Upper limit control 143 Hz + ON + ON
1-step increase from
(74 Hz + OFF + OFF) to
(Pc - Pe>0.4 MPa)
Outdoor unit fan
STEP8
or
STEP9
OFF STEP9
Four way valve ON OFF ON
Main motorized valve (EV1)
∗Value in ( ) are for RXYQ5M only.
SH control 0 pls (1400pls) 200 pls
Subcooling motorized valve (EV2) 0 pls 0 pls 0 pls
Hot gas bypass valve (SVP) OFF ON ON
Oil equalization valve (SVO) ON ON ON
Receiver gas charging valve (SVL) OFF OFF OFF
Receiver gas discharging valve
(SVG)
OFF OFF OFF
Non-operating unit gas discharging
valve (SVSG)
OFF OFF OFF
Non-operating unit liquid pipe stop
valve (SVSL)
ON ON ON
Ending conditions 2 min.
• 12 min.
• Ts >11°C
• 160 sec.
• Pc - Pe>0.4MPa
or
or
Indoor unit actuator During defrost
Fan
Thermostat ON unit OFF
Stopping unit OFF
Thermostat OFF unit OFF
Electronic expansion valve
Thermostat ON unit 512 pls
Stopping unit 512 pls
Thermostat OFF unit 512 pls
