Biostar A68MGP Версия 6.x [12/50] B memory capacity

Motherboard Manual

B. Memory Capacity

DIMM Socket Location

DDR3 Module

Total Memory Size

DDR3_A1 512MB/1GB/2GB/4GB/8GB/16GB

Max is 32GB.

DDR3_B1 512MB/1GB/2GB/4GB/8GB/16GB

C. Dual Channel Memory Installation

Please refer to the following requirements to activate Dual Channel function:

Install memory module of the same density in pairs, shown in the table.

Dual Channel Status DDR3_A1 DDR3_B1

Disabled O X

Disabled X O

Enabled O O

(O means memory installed, X means memory not installed.)

Note: The DRAM bus width of the memory module must be the same (x8 or x16)
