TA970

B. Memory Capacity

DIMM Socket

Location

DDR3 Module

Total Memory Size

DDR3_A1 512MB/1GB/2GB/4GB/8GB/16GB

DDR3_A2 512MB/1GB/2GB/4GB/8GB/16GB

DDR3_B1 512MB/1GB/2GB/4GB/8GB/16GB

DDR3_B2 512MB/1GB/2GB/4GB/8GB/16GB

Max is 64GB.

C. Dual Channel Memory Installation

Please refer to the following requirements to activate Dual Channel function:

Install memory module of the same density in pairs, shown in the table.

Dual Channel Status DDR3_A1 DDR3_A2 DDR3_B1 DDR3_B2

Enabled X O X O

Enabled O O O O

(O means memory installed, X means memory not installed.)

Note1: The DRAM bus width of the memory module must be the same (x8 or x16)

Note2: Memory module must be installed in DDR3-A2 or DDR3-B2 to boot the system.

D. DDR Speed Support

Please refer to the following table for DDR speed reference:

DDR Speed (1.5V)

# of DIMM per Channel

DDR3-1333 DDR3-1600 DDR3-1866

1 of 2 UDIMMs O O O

2 of 2 UDIMMs O O X
