![Biostar TA970 Plus Версия 5.x [4/51] Motherboard features](/views2/1711028/page4/bg4.png)
Motherboard Manual
2
1.3 Motherboard Features
SPEC
CPU
Socket AM3+
AMD Sempron / Phenom II / Athlon II /
FX processors (Maximum Watt: 140W)
AMD 64 Architecture enables 32 and 64 bit
computing
Supports Hyper Transport 3.0
FSB
Support HyperTransport 3.0
Supports up to 4.8 GT/s Bandwidth
Chipset
AMD 970
AMD SB950
Super I/O
IIT8728F-EX
Provides the most commonly used
legacy Super I/O functionality
Low Pin Count Interface
Environment Control initiatives
H/W Monitor
Fan Speed Controller
ITE's "Smart Guardian" function
Main
Memory
DDR3 DIMM Slots x 4
Max Memory Capacity 64GB
Each DIMM supports 512MB/
1GB/2GB/4GB/8GB/16GB DDR3
Dual Channel Mode DDR3 memory module
Supports DDR3 800/1066/1333/1600/1866
Supports DDR3 2000(OC)/ 2133(OC)
SATA III
Integrated Serial ATA Controller
Data transfer rates up to 6 Gb/s.
SATA Version 3.0 specification compliant.
RAID 0,1,5,10 support
LAN
Realtek RTL 8111GR
10 / 100 Mb/s / 1Gb/s auto negotiation
Half / Full duplex capability
Sound
ALC892
7.1channels audio out
Supports HD Audio, Biostar Hi-Fi
USB3.0
Asmedia ASM1042A Data transfer rates up to 600 MB/s
Slots
PCI Slot x2
PCI Express Gen2 x1 Slot x2
PCI Express Gen2 x16 Slot x2 Supports AMD CrossFireX™ (x16 + x4)
On Board
Connector
s
SATA Connector x5 Each connector supports 1 SATA device
mSATA Connector
(mini-PCIe Combo) x1
Each connector supports 1 mSATA or 1
mini-PCIe device
Front Panel Connector x1 Supports front panel facilities
Front Audio Connector x1 Supports front panel audio function
S/PDIF out Connector x1 Supports digital audio out function
Consumer IR Connector x1 Supports infrared function
CPU Fan Header x1
CPU Fan power supply (with Smart Fan
function)
System Fan Header x2 System Fan Power supply
