Motherboard Manual
2
1.3 MOTHERBOARD FEATURES
SPEC
CPU
Socket AM3+
AMD Sempron / Phenom II / Athlon II / FX
processors
AMD 64 Architecture enables 32 and 64 bit
comput ing
Supports Hyper Transport 3.0
FSB
Support HyperTransport 3.0
Supports up to 5.2 GT/s Bandwidth
Chipset
AMD 990FX
AMD SB950
Super I/O
ITE 8728
Provides the most commonly used legacy
Super I/O functionality
Low Pin Count Interface
Environment Control in it iatives
H/W Mon itor
Fan Sp eed Contro ller
ITE's "Smart Guard ian" function
Main
Memory
DDR3 DIMM Slots x 4
Max Memory Capacity 32GB
Each DIMM supports 512MB/
1GB/2GB/4GB/8GB DDR3
Dual Channel Mode DDR3 memory modu le
Supports DDR3 800/1066/1333/1600/1866
Supports DDR3 2000 (OC)
Registered DIMM and ECC DIMM is not supported
SATA III
Integrated Serial ATA Controller
Data transfer rates up to 6 Gb/s.
SATA Version 3.0 spe cif ic at ion co mp liant.
RAID 0,1,5,10 support
LAN
AR8151
10 / 100 Mb/s / 1Gb/s auto negotiation
Half / Full duplex capability
Sound
ALC892
7.1channels audio out
Supports HD Audio
USB3.0
Asmedia ASM1042 Data transfer rates up to 600 MB/s
IEEE 1394
VIA VT6315N 1394a
PCI Slot x2 Supports PCI expansion cards
PCI Express Gen2 x1 Slot x1 Supports PCI-E Gen2 x1 expansion card
Slots
PCI Express Gen2 x16 Slot x3 Supports PCI-E Gen2 x16,x16, x4, expansion cards
SATA Connector x5 Each connector supports 1 SATA device
Front Panel Connector x1 Supports front panel facilities
Front Audio Connector x1 Supports front panel audio function
S/PDIF out Connector x1 Supports digital audio out function
Consumer IR Connector x1 Supports infrared function
CPU Fan Header x1 CPU Fan power supply (with Smart Fan function)
System Fan Header x2 System Fan Power supply
CMOS clear Header x1 Restore CMOS data to factory default
On Board
Connectors
USB2.0 Connector x2 Each connector supports 2 front panel USB2.0 ports
