Motherboard Manual
2
1.3 MOTHERBOARD FEATURES
SPEC
CPU
Socket FM1
AMD A-Series / E2-Series / Athlon II /
Sempron processors
AMD 64 Architecture enables 32 and 64 bit
comput ing
Chipset AMD A55
Super I/O
ITE 8728
Provides the most commonly used legacy
Super I/O functionality
Low Pin Count Interface
Env ironment Control in it iatives
H/W Mon itor
Fan Sp eed Contro ller
ITE's "Smart Guard ian" funct ion
Main
Memory
DDR3 DIMM Slots x 2
Max Memory Capacity 16GB
Each DIMM supports 512MB/
1GB/2GB/4GB/8GB DDR3
Dual Channel Mode DDR3 memory modu le
Supports DDR3 800/1066/1333/1600/1866
Registered DIMM and ECC DIMM is not supported
SATA II Integrated Serial ATA Controller
Data transfer rates up to 3 Gb/s.
SATA Version 2.0 specif ic at ion co mp liant.
RAID 0,1,10 support
LAN
RTL8105E (A55ML+)
RTL8111E/ RTL8111F (A55MG+)
10 / 100 Mb/s auto negotiation
10 / 100 Mb/s / 1Gb/s auto negotiation
Half / Full duplex capability
Sound ALC662
5.1channels audio out
Supports HD Audio
PCI Express Gen2 x16 Slot x1
Supports PCI-E Gen2 x16 expansion card
PCI Express Gen2 x1 Slot x2
Supports PCI-E Gen2 x1 expansion card
Slots
PCI Slot x1
Supports PCI expansion card
SATA Connector x4 Each connector supports 1 SATA device
Front Panel Connector x1 Supports front panel facilities
Front Audio Connector x1 Supports front panel audio function
CPU Fan Header x1 CPU Fan power supply (with Smart Fan function)
On Board
Connectors
System Fan Header x1 System Fan Power supply
