Product Outline SiUS39-504
4 General Information
1.3 Model Selection
VRV II Heat Pump Series
Connectable Indoor Units Number and Capacity
Connectable Indoor Unit
Indoor Unit Capacity
Use the above tables to determine the capacities of indoor units to be connected. Make sure the
total capacity of indoor units connected to each outdoor unit is within the specified value (Btu/h).
The total capacity of connected indoor units must be within a range of 50 to 130% of the rated
capacity of the outdoor unit.
In some models, it is not possible to connect the maximum number of connectable indoor units.
Select models so the total capacity of connected indoor units conforms to the specification.
Ton 8 ton 16 ton
System name RXYQ96M RXYQ192M
Outdoor unit 1 RXYQ96M RXYQ96M
Outdoor unit 2 — RXYQ96M
Total number of connectable indoor units 10 20
Total capacity of connectable indoor units (MBtu/h) 48~120 96~240
Type Model Name Power Supply
Ceiling mounted cassette
type (Multi flow)
FXFQ 12M 18M 24M 30M 36M —
VJU
Ceiling mounted
built-in type
FXSQ 12M 18M 24M 30M 36M 48M
Ceiling mounted
duct type
FXMQ — — — 30M 36M 48M
Ceiling suspended
Type
FXHQ 12M — 24M — 36M —
Wall mounted type
FXAQ 12M 18M 24M — — —
Floor standing type
FXLQ 12M 18M 24M — — —
Concealed Floor
standing type
FXNQ 12M 18M 24M — — —
New refrigerant model code 12 type 18 type 24 type 30 type 36 type 48 type
Selecting model capacity 12,000
Btu/h
18,000
Btu/h
24,000
Btu/h
30,000
Btu/h
36,000
Btu/h
48,000
Btu/h
Equivalent output 1 ton 1.5 ton
2
ton
2.5 ton 3 ton 4 ton
